Mitsubishi R2500

The Mitsubishi R2500 is a tractor produced by Mitsubishi. It is equipped with a 72.7 ci 1.2 L engine. The rated power output is 25 hp 18.6 kW. Transmission: 6 forward and 2 reverse. Operating weight: 1940 lbs 879 kg.

Overview

	1970 - 1975 Compact Utility tractor
1970 - 1975
Compact Utility tractor

1970 - 1975
Compact Utility tractor

Production
Manufacturer	Mitsubishi
Compact Utility tractor

Variants
R2500HC	high clearance

Mitsubishi R2500 Engine
Mitsubishi 1.2L 2-cyl diesel
Engine details ...

Mitsubishi R2500 Transmission
6-speed
Transmission details ...

Mitsubishi R2500 Power
Engine	25 hp 18.6 kW

Mechanical
Two-wheel drive
Final drives	spur gear
Differential lock	mechanical rear
Manual steering
Mechanical drum brakes
Open operator station.

Tractor hitch
Rear Type	I
Control	position control with optional draft control
Rear lift (at ends)	1750 lbs 793 kg

Power Take-off (PTO)
Clutch	544:2400
	835:2400
Rear PTO Type	540 (1.375)

Dimensions & Tires
Wheelbase	58.7 inches 149 cm
Weight	1940 to 2050 pounds
Front tire	5.00-15
Rear tire	9.5/9-24
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
Farm Tractor R2500 published in 1969, by Mitsubishi

Engine

	1970 - 1975 Compact Utility tractor
1970 - 1975
Compact Utility tractor

1970 - 1975
Compact Utility tractor

Engine Detail
Mitsubishi 2DR
diesel
2-cylinder
liquid-cooled
Displacement	72.7 ci 1.2 L
Bore/Stroke	3.46x3.86 inches 88 x 98 mm
Power	25 hp 18.6 kW
Starter	electric
Starter volts	12

Transmission

	1970 - 1975 Compact Utility tractor
1970 - 1975
Compact Utility tractor

1970 - 1975
Compact Utility tractor

Transmission
Gears	6 forward and 2 reverse
Clutch	210mm dry disc

Speeds

Dimensions

	1970 - 1975 Compact Utility tractor
1970 - 1975
Compact Utility tractor

1970 - 1975
Compact Utility tractor

Mitsubishi R2500 Tires
Optional tires (ag)	Front: 11.2/1-24. Rear:
	Front: 12.4/11-24. Rear:
	Front: 11.2/10-28. Rear:
Ag front	5.00-15
Ag rear	9.5/9-24

Dimensions
Wheelbase	58.7 inches 149 cm
Length	92.1 inches 233 cm
HC Length	94.2 inches 239 cm
Width	59.9 inches 152 cm
Weight	1940 lbs 879 kg
HC Weight	2050 lbs 929 kg
Ground clearance	16.2 inches 41 cm
HC Ground clearance	19.3 inches 49 cm
Front tread	42 to 58 inches 106 to 147 cm
Rear tread	38 to 59 inches 96 to 149 cm

Mitsubishi R2500 Height
Steering wheel	53.5 inches 135 cm
HC Steering wheel	56.6 inches 143 cm
Exhaust	68 inches 172 cm
HC Exhaust	71.1 inches 180 cm

Photos

Mitsubishi R2500 tractor photo
