new holland 3930
 | 1990 - 2002
30 SeriesUtility tractor | 1990 - 2002 | 30 Series | Utility tractor |
|---|---|---|---|---|
1990 - 2002 | ||||
30 Series | ||||
Utility tractor | ||||
1990 - 2002 | |
|---|---|
30 Series | |
Utility tractor |
Series map: 34303930463046.0hp50.0hp*60.0hp3910↓ 1983-1989
Note: the New Holland model 3930 is the same as the Ford 3930. The following data is from the 3930 listing. |
|---|
Tractor Tests | |
|---|---|
OECD 1644: 3.3L diesel 8x2 speed 4WD | |
OECD 1341: diesel 8x8 speed | |
OECD 1701: 3.1L diesel 8x2 speed 4WD | |
OECD 1702: 3.1L diesel 8x8 speed 4WD | |
OECD 1702S: 3.1L turbo-diesel 8x8 speed 4WD |
OCED Tractor Test 1644 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1644 | |
|---|---|
3.3L diesel 8x2 speed 4WD
April 8 - 25, 1991
Link: OCED Tractor Test 1644 file | |
PTO performance | |
Power at rated engine speed | 45.85 hp
34.2 kW |
Fuel use | 2.8 gal/hour
10.6 l/hour |
Power at rated PTO speed | 43.65 hp
32.5 kW |
Fuel use | 2.6 gal/hour
9.8 l/hour |
Drawbar performance | |
Max power | 38.18 hp
28.5 kW |
Fuel use | 2.9 gal/hour
11.0 l/hour |
Gear 1H used for power test. | |
Max pull | 4,807 lbs
2180 kg |
Gear 2L used for pull test. | |
OCED Tractor Test 1341 | |
|---|---|
Diesel 8x8 speed | |
PTO performance | |
Max power | 44.3 hp
33.0 kW |
Fuel use | 2.9 gal/hour
11.0 l/hour |
Drawbar performance | |
Max power | 35.1 hp
26.2 kW |
OCED Tractor Test 1701 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1701 | |
|---|---|
3.1L diesel 8x2 speed 4WD
October 17 - 27, 1995
Link: OCED Tractor Test 1701 file | |
PTO performance | |
Power at rated engine speed | 45.58 hp
34.0 kW |
Fuel use | 3.0 gal/hour
11.4 l/hour |
Power at rated PTO speed | 41.22 hp
30.7 kW |
Fuel use | 2.6 gal/hour
9.8 l/hour |
Drawbar performance | |
Max power | 37.33 hp
27.8 kW |
Gear 1H used for power test. | |
Max pull | 5,026 lbs
2279 kg |
Gear 2L used for pull test. | |
OCED Tractor Test 1702 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1702 | |
|---|---|
3.1L diesel 8x8 speed 4WD
October 2 - 27, 1995
Link: OCED Tractor Test 1702 file | |
PTO performance | |
Power at rated engine speed | 46.23 hp
34.5 kW |
Fuel use | 3.2 gal/hour
12.1 l/hour |
Power at rated PTO speed | 41.81 hp
31.2 kW |
Fuel use | 2.7 gal/hour
10.2 l/hour |
Drawbar performance | |
Max power | 37.19 hp
27.7 kW |
Fuel use | 3.1 gal/hour
11.7 l/hour |
Gear 1H used for power test. | |
Max pull | 4,480 lbs
2032 kg |
Gear 3L used for pull test. | |
OCED Tractor Test 1702S | |
|---|---|
3.1L turbo-diesel 8x8 speed 4WD
1998 | |
PTO performance | |
Power at rated engine speed | 52.54 hp
39.2 kW |
