new holland 7740
 | 1996 - 1997
PowerStar 40 SeriesRow-Crop tractor | 1996 - 1997 | PowerStar 40 Series | Row-Crop tractor |
|---|---|---|---|---|
1996 - 1997 | ||||
PowerStar 40 Series | ||||
Row-Crop tractor | ||||
1996 - 1997 | |
|---|---|
PowerStar 40 Series | |
Row-Crop tractor |
Series map: TS110↑ 1999-200366407740784090.7hp100.3hp100.0hp*7740↓ 1991-1995*Estimated engine power for comparison only.
Note: the New Holland model 7740 is the same as the Ford 7740. The following data is from the 7740 listing. |
|---|
Tractor Tests | |
|---|---|
OECD 1658: diesel 16x4 4WD | |
OECD 1705: diesel 16x16 4WD |
OCED Tractor Test 1658 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1658 | |
|---|---|
Diesel 16x4 4WD
May 6 - 13, 1992
Link: OCED Tractor Test 1658 file | |
PTO performance | |
Power at rated engine speed | 86.86 hp
64.8 kW |
Fuel use | 5.2 gal/hour
19.7 l/hour |
Power at rated PTO speed | 87.24 hp
65.1 kW |
Fuel use | 5.1 gal/hour
19.3 l/hour |
Drawbar performance | |
Max power | 76.93 hp
57.4 kW |
Fuel use | 5.2 gal/hour
19.7 l/hour |
Gear 5-Low used for power test. | |
Max pull | 11,352 lbs
5149 kg |
Gear 2H used for pull test. | |
OCED Tractor Test 1705 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1705 | |
|---|---|
Diesel 16x16 4WD
October 9 - 23, 1995
Link: OCED Tractor Test 1705 file | |
PTO performance | |
Power at rated engine speed | 86.96 hp
64.8 kW |
Fuel use | 5.4 gal/hour
20.4 l/hour |
Power at rated PTO speed | 86.41 hp
64.4 kW |
Fuel use | 5.3 gal/hour
20.1 l/hour |
Drawbar performance | |
Max power | 74.15 hp
55.3 kW |
Fuel use | 5.4 gal/hour
20.4 l/hour |
Gear 6-Low used for power test. | |
Max pull | 10,210 lbs
4631 kg |
Gear 4L used for pull test. | |
