Poloron 6501M
The Poloron 6501M is a tractor produced by Poloron Lawn Tractors. The listed engine power is Gasoline (gross): 8 hp / 6.0 kW. Drive type: belt.
Engine Power
Gasoline (gross): 8 hp / 6.0 kW
Drive & Traction
belt
Fuel & Capacities
Gasoline
Overview
 | 1976
Lawn tractorGarton built
Lawn tractor
Garton built |
|---|
Production | |
|---|---|
Distributor | Poloron |
Manufacturer | Garton |
Lawn tractor | |
Built in Sheboygan, Wisconsin, USA | |
Poloron 6501M Engine | |
|---|---|
8HP 1-cyl gasoline | |
Engine details ...  |
Poloron 6501M Transmission | |
|---|---|
gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Mid PTO Type | pulley |
Dimensions & Tires | |
|---|---|
Front tire | 15x6.00 |
Rear tire | 18x9.50 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Operating Manual for 38" Lawn Tractors Models 6501M, 6502M and 6504M (116891) published in 1976 | |
Dealer Service Guide published in 1974 |
Engine
Engine Detail — Gasoline
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Power (gross) | 8 hp
6.0 kW |
Fuel system | carburetor |
Starter type | manual recoil |
Transmission
Transmission — belt-driven gear
Type | belt-driven gear |
Dimensions
Poloron 6501M Tires | |
|---|---|
Lawn/turf front | 15x6.00 |
Lawn/turf rear | 18x9.50 |
Dimensions |
|---|
Attachments
38" Mower deck | |
|---|---|
Type | mid-mount Poloron |
2-blade | |
Cutting width | 38 inches
96 cm |
Drive | belt |
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Poloron Lawn Tractors Poloron 6501M.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Poloron Lawn Tractors Poloron 6501M Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Poloron Lawn Tractors Poloron 6501M.
Converted Equivalents:
Horsepower (HP)8 hp
Kilowatts (kW)6 kW
Metric Horsepower (PS / CV)8.1 PS
