Poloron 8602M

The Poloron 8602M is a tractor produced by Poloron Lawn Tractors. The listed engine power is Gasoline (gross): 8 hp / 6.0 kW. Drive type: belt.

Engine Power
Gasoline (gross): 8 hp / 6.0 kW
Drive & Traction
belt
Fuel & Capacities
Gasoline

Overview

Poloron 8602M tractor photo
1976 Lawn tractorGarton built Lawn tractor Garton built
Production
Distributor
Poloron
Manufacturer
Garton
Lawn tractor
Built in Sheboygan, Wisconsin, USA
Poloron 8602M Engine
8HP 1-cyl gasoline
Engine details ...
Poloron 8602M Transmission
gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station
Power Take-off (PTO)
Mid PTO
independent
Clutch
manual
Mid PTO Type
pulley
Dimensions & Tires
Full dimensions and tires ...
Electrical
Ground
negative
Battery volts
12
References
8602M references literature
Owner's Manual Models 8602M and 8604M (116970) published in 1976
Dealer Service Guide published in 1974

Engine

Engine Detail — Gasoline

Fuel Type
Gasoline
Configuration
1-cylinder, air-cooled vertical-shaft
Power (gross)
8 hp 6.0 kW
Fuel system
carburetor
Starter
electric
Starter volts
12

Transmission

Transmission — belt-driven gear

Type
belt-driven gear

Dimensions

Poloron 8602M Tires
Dimensions

Attachments

38" Mower deck
Type
mid-mount Poloron
2-blade
Cutting width
38 inches 96 cm
Drive
belt

Photos

Poloron 8602M tractor photo

Poloron 8602M tractor photo

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Poloron Lawn Tractors Poloron 8602M.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Poloron Lawn Tractors Poloron 8602M Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Poloron Lawn Tractors Poloron 8602M.

Converted Equivalents:

Horsepower (HP)8 hp
Kilowatts (kW)6 kW
Metric Horsepower (PS / CV)8.1 PS
