Snapper 28086
The Snapper 28086 is a tractor produced by Snapper Lawn Tractors. The rated power output is 8 hp 6.0 kW. Transmission: 5 forward and reverse.
Overview
 | 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Production | |
|---|---|
Manufacturer | Snapper |
Riding lawn mower | |
Snapper 28086 Engine | |
|---|---|
8HP Briggs & Stratton gasoline | |
Fuel tank | 1.25 gal
4.7 L |
Engine details ...  | |
Snapper 28086 Transmission | |
|---|---|
5-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering |
Dimensions & Tires | |
|---|---|
Front tire | 10.5x4.1-4 |
Rear tire | 16x6.5-8 |
Full dimensions and tires ...  | |
Snapper 28086 attachments | |
|---|---|
28" mid-mount mower deck | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Rear engine riding mowers published in 1989, by Snapper |
Engine
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Engine Detail | |
|---|---|
Briggs & Stratton | |
gasoline | |
air-cooled vertical-shaft | |
Power (gross) | 8 hp
6.0 kW |
Starter | manual recoil |
electric OptOptional | |
Starter volts | 12 |
Transmission
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Transmission | |
|---|---|
Type | friction disc |
Gears | 5 forward and reverse |
Dimensions
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Snapper 28086 Tires | |
|---|---|
Lawn/turf front | 10.5x4.1-4 |
Lawn/turf rear | 16x6.5-8 |
Dimensions |
|---|
Attachments
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
28" Mower deck | |
|---|---|
Type | mid-mount Snapper |
1-blade with manual lift | |
Cutting width | 28 inches
71 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Cut positions | 6 |
Photos
Snapper 28086 tractor photo
