Snapper 30086
The Snapper 30086 is a tractor produced by Snapper Lawn Tractors. The rated power output is 8 hp 6.0 kW. Transmission: 5 forward and reverse.
Engine Power
8 hp
6.0 kW
Fuel & Capacities
1.25 gal
4.7 L
Transmission
5 forward and reverse
Snapper Lawn Tractors Snapper 30086 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Production | |
|---|---|
Manufacturer | Snapper |
Riding lawn mower | |
Snapper 30086 Engine | |
|---|---|
8HP Briggs & Stratton gasoline | |
Fuel tank | 1.25 gal
4.7 L |
Engine details ...  | |
Snapper 30086 Transmission | |
|---|---|
5-speed friction disc | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering |
Dimensions & Tires | |
|---|---|
Front tire | 10.5x4.1-4 |
Rear tire | 16x6.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Rear engine riding mowers published in 1989, by Snapper |
Engine
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Engine Detail — Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | air-cooled vertical-shaft |
Power (gross) | 8 hp
6.0 kW |
Starter | manual recoil |
electric OptOptional | |
Starter volts | 12 |
Transmission
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Transmission — 5 forward and reverse friction disc
Type | friction disc |
Gears | 5 forward and reverse |
Dimensions
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
Snapper 30086 Tires | |
|---|---|
Lawn/turf front | 10.5x4.1-4 |
Lawn/turf rear | 16x6.5-8 |
Dimensions |
|---|
Attachments
| 1987 - 1989
6 SeriesRiding lawn mower |
|---|---|
1987 - 1989 | |
6 Series | |
Riding lawn mower | |
1987 - 1989 | |
|---|---|
6 Series | |
Riding lawn mower |
30" Mower deck | |
|---|---|
Type | mid-mount Snapper |
1-blade with manual lift | |
Cutting width | 30 inches
76 cm |
Cut height | 1 to 4 inch
2 to 10 cm |
Cut positions | 6 |
Photos
Snapper 30086 tractor photo
