Toro 13-32 70131
The Toro 13-32 70131 is a tractor produced by Toro Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The listed engine power is Gasoline (gross): 13 hp / 9.7 kW. Transmission: Peerless 915.
Engine Power
Gasoline (gross): 13 hp / 9.7 kW
Fuel & Capacities
1 gal
3.8 L
Transmission
Peerless 915
Overview
 | 1996 - 1997
Riding lawn mower |
|---|
Production | |
|---|---|
Manufacturer | Toro |
Riding lawn mower | |
Toro 13-32 Engine | |
|---|---|
13HP Briggs & Stratton 465cc 1-cyl gasoline | |
Fuel tank | 1 gal
3.8 L |
Engine details ...  | |
Toro 13-32 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual |
Dimensions & Tires | |
|---|---|
Wheelbase | 44 inches
111 cm |
Front tire | 11x4.00 |
Rear tire | 15x6.00 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery CCA | 160 |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn Tractors & Rear Engine Riders published in 1996, by Toro |
Engine
Engine Detail — 465 cc / 28.4 ci Gasoline
Manufacturer | Briggs & Stratton 28M707 |
Fuel Type | Gasoline |
Configuration | 1-cylinder, air-cooled vertical-shaft |
Displacement | 465 cc
28.4 ci |
Bore/Stroke | 3.44x3.06 inches
87 x 78 mm |
Power (gross) | 13 hp
9.7 kW |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Peerless 915
Transmission | Peerless 915 |
Type | belt-driven gear |
Gears | 5 forward and 1 reverse |
 | |
Dimensions
Toro 13-32 Tires | |
|---|---|
Lawn/turf front | 11x4.00 |
Lawn/turf rear | 15x6.00 |
Dimensions | |
|---|---|
Wheelbase | 44 inches
111 cm |
Length | 60 inches
152 cm |
Attachments
32" Mower deck | |
|---|---|
Type | mid-mount Toro |
1-blade | |
Cutting width | 32 inches
81 cm |
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Toro Lawn Tractors Toro 13-32 70131.
Estimated Continuous Field Runtime: 1.5 hrs
Approximately 1.5 hours of continuous field operation at ~75% rated power on a full tank (1 gal / 3.8 L).
Estimated 75% Load Fuel Burn~0.7 gal/hr (2.6 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Toro Lawn Tractors Toro 13-32 70131 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Toro Lawn Tractors Toro 13-32 70131.
Converted Equivalents:
Horsepower (HP)13 hp
Kilowatts (kW)9.7 kW
Metric Horsepower (PS / CV)13.2 PS
