Toro Suburban 10 55301

The Toro Suburban 10 55301 is a tractor produced by Toro Lawn Tractors. It is equipped with a 390 cc 23.85 ci engine. The listed engine power is Gasoline (gross): 10 hp / 7.5 kW. Transmission: Peerless 2301. Drive type: belt. Operating weight: 113 lbs 51 kg.

Engine Power
Gasoline (gross): 10 hp / 7.5 kW
Drive & Traction
belt
Fuel & Capacities
2 gal 7.6 L
Transmission
Peerless 2301
Operating Weight
113 lbs 51 kg

Overview

Toro Suburban 10 55301 tractor photo
1968 Suburban SeriesGarden tractor Suburban Series Garden tractor
Production
Manufacturer
Toro
Garden tractor
Toro Suburban 10 Engine
10HP Kohler 390cc 1-cyl gasoline
Fuel tank
2 gal 7.6 L
Engine details ...
Toro Suburban 10 Transmission
4-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Power Take-off (PTO)
Mid PTO
independent
Clutch
manual
Dimensions & Tires
Wheelbase
46 inches 116 cm
Weight
585 lbs 265 kg
Front tire
4.00/4.80x8
Rear tire
8.0x12
Full dimensions and tires ...
Electrical
Ground
negative
Charging system
starter-generator
Battery volts
12
References
Suburban 10 55301 references literature
The "Worth" Mower published in 1968, by Toro
Lawn Tractors - Riding Mowers - Suburban Tractors published in 1968, by Toro
Operator's Manual Suburban Tractors (172-68) published in 1967

Engine

Engine Detail — 390 cc / 23.85 ci Gasoline

Manufacturer
Kohler K241AS
Fuel Type
Gasoline
Configuration
1-cylinder, air-cooled horizontal-shaft
Displacement
390 cc 23.85 ci
Bore/Stroke
3.25x2.875 inches 83 x 73 mm
Power (gross)
10 hp 7.5 kW
Fuel system
carburetor
Air cleaner
dry
Starter
electric
Starter volts
12
Oil capacity
1.5 qts 1.4 L

Transmission

Transmission — Peerless 2301

Transmission
Peerless 2301
Type
belt-driven gear
Gears
4 forward and 1 reverse
Clutch
mechanical idler pulley
Suburban 10 55301 2301 belt-driven gear speeds

Dimensions

Toro Suburban 10 Tires
Lawn/turf front
4.00/4.80x8
Lawn/turf rear
8.0x12
Dimensions
Wheelbase
46 inches 116 cm
Length
67.5 inches 171 cm
Width
36 inches 91 cm
Height
38 inches 96 cm
Weight
585 lbs 265 kg

Attachments

Attachment overview
42" mid-mount mower deck
Snowblower
Blade
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.
42" Mower deck
Type
mid-mount Toro
2-blade with manual lift
Cutting width
42 inches 106 cm
Drive
belt
Weight
113 lbs 51 kg
Cut height
2 to 4 inch 5 to 10 cm
Cut positions
5

Photos

Toro Suburban 10 55301 tractor photo

Toro Suburban 10 55301 tractor photo

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Toro Lawn Tractors Toro Suburban 10 55301.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Toro Lawn Tractors Toro Suburban 10 55301 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Toro Lawn Tractors Toro Suburban 10 55301.

Converted Equivalents:

Horsepower (HP)10 hp
Kilowatts (kW)7.5 kW
Metric Horsepower (PS / CV)10.1 PS
