Toro Suburban 8 55200

The Toro Suburban 8 55200 is a tractor produced by Toro Lawn Tractors. It is equipped with a 305 cc 18.64 ci engine. The rated power output is 8 hp 6.0 kW. Transmission: Peerless 1700. Drive type: belt.

Overview

	1967 Suburban Compact SeriesGarden tractor
1967
Suburban Compact Series
Garden tractor

Production
Manufacturer	Toro
Garden tractor
Original price was $880 in 1967

Toro Suburban 8 Engine
8HP Kohler 305cc 1-cyl gasoline
Engine details ...

Toro Suburban 8 Transmission
3-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes

Power Take-off (PTO)
Mid PTO	independent
Clutch	manual

Dimensions & Tires
Front tire	4.80-8
Rear tire	6.00-12
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	starter-generator
Battery volts	12

References
Toro 1967
Home Utility Tractors published in 1967, by Toro
Operator's Manual Suburban Tractors (172-67) published in 1966

Engine

Engine Detail — 305 cc / 18.64 ci Gasoline

Manufacturer	Kohler K181S
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled horizontal-shaft
Displacement	305 cc 18.64 ci
Bore/Stroke	2.9375x2.75 inches 75 x 70 mm
Power (gross)	8 hp 6.0 kW
Air cleaner	dry
Starter	electric
Starter volts	12

Transmission

Transmission — Peerless 1700

Transmission	Peerless 1700
Type	belt-driven gear
Gears	3 forward and 1 reverse
Clutch	mechanical idler pulley

Dimensions

Toro Suburban 8 Tires
Lawn/turf front	4.80-8
Lawn/turf rear	6.00-12

Dimensions

Attachments

Attachment overview
42" mid-mount mower deck
Snowblower
Blade
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

42" Mower deck
Type	mid-mount Toro 59004
	2-blade with manual lift
Cutting width	42 inches 106 cm
Drive	belt
Cut height	2 to 4 inch 5 to 10 cm
Cut positions	5

Photos

Toro Suburban 8 55200 tractor photo
