Troy-Bilt 13095 LTX 13

The Troy-Bilt 13095 LTX 13 is a tractor produced by Troy Bilt Lawn Tractors. It is equipped with a 465 cc 28.4 ci engine. The rated power output is 13 hp 9.7 kW. Transmission: Peerless MST 205. Operating weight: 383 lbs 173 kg.

Overview

	1996 - 1997 LTX SeriesLawn tractor
1996 - 1997
LTX Series
Lawn tractor

Production
Manufacturer	Troy-Bilt
Lawn tractor
Built in Port Washington, Wisconsin, USA

Troy-Bilt 13095 Engine
13HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank	4 gal 15.1 L
Engine details ...

Troy-Bilt 13095 Transmission
5-speed gear
Transmission details ...

Mechanical
Two-wheel drive
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	48.25 inches 122 cm
Weight	383 lbs 173 kg
Front tire	15x6.00-6
Rear tire	20x8.00-8
Full dimensions and tires ...

Electrical
Ground	negative
Battery CCA	190
Battery volts	12

References
Owner/Operator Manual Models 13095, 13096, 13097, 13099 (1772619) published in 1999

Engine

Engine Detail — 465 cc / 28.4 ci Gasoline

Manufacturer	Briggs & Stratton 28M707
Fuel Type	Gasoline
Configuration	1-cylinder, air-cooled vertical-shaft
Displacement	465 cc 28.4 ci
Bore/Stroke	3.44x3.06 inches 87 x 78 mm
Power	13 hp 9.7 kW
Starter	electric
Starter volts	12

Transmission

Transmission — Peerless MST 205

Transmission	Peerless MST 205
Type	belt-driven gear
Gears	5 forward and 1 reverse

Dimensions

Troy-Bilt 13095 Tires
Lawn/turf front	15x6.00-6
Lawn/turf rear	20x8.00-8

Dimensions
Wheelbase	48.25 inches 122 cm
Length	72 inches 182 cm
Width	35 inches 88 cm
Height	43 inches 109 cm
Shipping weight	383 lbs 173 kg
Ground clearance	6.25 inches 15 cm

Attachments

Attachment overview
42" mid-mount mower deck
Snowblower
Blade

42" Mower deck
Type	mid-mount Troy-Bilt 14051
	3-blade with manual lift
Cutting width	42 inches 106 cm

Photos

Troy-Bilt 13095 LTX 13 tractor photo
