Ursus C-385

The Ursus C-385 is a tractor produced by Ursus. It is equipped with a 279.4 ci 4.6 L engine. The rated power output is 85 hp 63.4 kW. Transmission: 16 forward and 8 reverse. Operating weight: 9943 to 10910 pounds.

Overview

	1972 - 1983	1972 - 1983

Production
Manufacturer	Ursus

Variants
C-385	2WD
C-385A	4WD

Ursus C-385 Transmission
16-speed partial power shift
Transmission details ...

Ursus C-385 Power
Engine	85 hp 63.4 kW

Mechanical
Two- or four-wheel drive
Steering	power assist
Differential hydraulic disc brakes

Hydraulics
Pump flow	9.2 gpm 34.8 lpm

Power Take-off (PTO)
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	93.9 inches 238 cm
Weight	9943 to 10910 pounds
Front tire	7.50-20
Rear tire	16.9-34
Full dimensions and tires ...

References
C385, C385A published in 1975, by Ursus

Engine

Engine options
4.6L 4-cyl diesel
4.6L 4-cyl

Engine Detail — 279.4 ci / 4.6 L Diesel

Manufacturer	Z-7501
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	279.4 ci 4.6 L
Bore/Stroke	4.33x4.72 inches 110 x 120 mm
Power	85 hp 63.4 kW
Air cleaner	dry two stage
Compression	17:1
Rated RPM	2200
Torque	197.7 lb-ft 268.1 Nm
Torque RPM	1130

Engine Detail — 279.4 ci / 4.6 L

Configuration	turbocharged, 4-cylinder
Displacement	279.4 ci 4.6 L
Bore/Stroke	4.33x4.72 inches 110 x 120 mm
Rated RPM	2200
Torque	236.0 lb-ft 320.0 Nm
Torque RPM	1650

Transmission

Transmission — 16 forward and 8 reverse partial power shift

Type	partial power shift
Gears	16 forward and 8 reverse
A 8-forward and 4-reverse gearbox with a torque amplifier style power shift that doubles the available speeds.
With 16.9-34 rear tires.

Dimensions

Ursus C-385 Tires
Ag front	7.50-20 (2WD)
	12.4-24 (4WD)
Ag rear	16.9-34

Dimensions
Wheelbase	93.9 inches 238 cm
Length	155.3 inches 394 cm
Width	76 inches 193 cm
Height (cab)	97.8 inches 248 cm
2WD cab Weight	9943 lbs 4510 kg
4WD cab Weight	10910 lbs 4948 kg
Ground clearance	16.5 inches 41 cm

Photos

Ursus C-385 and C-385A tractors

Cab interior of the Ursus C-385
