Valmet 6750
The Valmet 6750 is a tractor produced by Valmet. It is equipped with a 268.4 ci 4.4 L engine. The listed engine power is Diesel (listed): 104.6 hp / 78.0 kW. Transmission: HiTech. Operating weight: 10251 lbs 4649 kg.
Engine Power
Diesel (listed): 104.6 hp / 78.0 kW
Fuel & Capacities
43.6 gal
165.0 L
Transmission
HiTech
Operating Weight
10251 lbs
4649 kg
Overview
 | 2002 - 2003
HiTech 6050 SeriesRow-Crop tractor
HiTech 6050 Series
Row-Crop tractor |
|---|
Production | |
|---|---|
Manufacturer | Valmet |
Row-Crop tractor | |
Valmet 6750 Engine | |
|---|---|
Valmet 4.4L 4-cyl diesel | |
Fuel tank | 43.6 gal
165.0 L |
Engine details ...  | |
Valmet 6750 Transmission | |
|---|---|
36-speed three-speed power shift | |
Transmission details ...  |
Valmet 6750 Power | |
|---|---|
Engine | 104.6 hp
78.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Cab standard. |
Hydraulics | |
|---|---|
Pump flow | 19.3 gpm
73.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 15432 lbs
6999 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 91.6 inches
232 cm |
Weight | 10251 lbs
4649 kg |
Front tire | 14.9R28 |
Rear tire | 18.4R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
Battery AH | 184 |
Engine
Engine Detail — 268.4 ci / 4.4 L Diesel
Manufacturer | Valmet 420 DWRIE |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 268.4 ci
4.4 L |
Bore/Stroke | 4.25x4.72 inches
108 x 120 mm |
Power | 104.6 hp
78.0 kW |
Rated RPM | 1600 |
Torque | 390.9 lb-ft
530.1 Nm |
Torque RPM | 1150 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — HiTech
Transmission | HiTech |
Type | three-speed power shift |
Gears | 36 forward and reverse |
Four gears in three ranges with three-speed power shift and shuttle. | |
With 18.4R38 rear tires. | |
 | |
Dimensions
Valmet 6750 Tires | |
|---|---|
Standard tires (ag) | Front: 14.9R28. Rear: 18.4R38 |
Optional tires (ag) | Front: 480/65R28. Rear: 600/65R38 |
Dimensions | |
|---|---|
Wheelbase | 91.6 inches
232 cm |
Length | 178.3 inches
452 cm |
Width | 85.8 inches
217 cm |
Height (cab) | 110 inches
279 cm |
Height (exhaust) | 109.8 inches
278 cm |
Weight | 10251 lbs
4649 kg |
Clearance (front axle) | 20.1 inches
51 cm |
Clearance (rear axle) | 19.7 inches
50 cm |
Recommended Implements & Sizing Guide
Engineering recommendations for Valmet 6750 based on its 104.6 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 4 to 5 Bottom (16-18")4 - 5 铧 (40-45 cm) | Heavy Duty | Heavy primary tillage; semi-mounted hitch recommended. |
Rotary Cutter / MowerMowing & Clearing | 10 to 12 ft Flex-Wing3.0 - 3.6 m 折叠双翼 | Heavy Duty | Wide swath pasture and crop residue shredding. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙 | Heavy Duty | Aggressive residue cutting in corn/cotton stubble. |
Hay BalerHay & Forage | 5x6 Round Baler or 3x3 Mid Square1.5x1.8 m 大圆捆或中型方捆机 | Heavy Duty | High density baling; requires minimum 85 PTO HP. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Valmet 6750.
Estimated Continuous Field Runtime: 8 hrs
Approximately 8 hours of continuous field operation at ~75% rated power on a full tank (43.6 gal / 165 L).
Estimated 75% Load Fuel Burn~5.4 gal/hr (20.6 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Valmet 6750 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Valmet 6750.
Converted Equivalents:
Horsepower (HP)104.6 hp
Kilowatts (kW)78 kW
Metric Horsepower (PS / CV)106.1 PS
