Valtra N104
The Valtra N104 is a tractor produced by Valtra. It is equipped with a 268.4 ci 4.4 L engine. The rated power output is 103.3 hp 77.0 kW. Transmission: Hi Tech. Operating weight: 11795 lbs 5350 kg.
Engine Power
103.3 hp
77.0 kW
Fuel & Capacities
62.1 gal
235.0 L
Transmission
Hi Tech
Operating Weight
11795 lbs
5350 kg
Valtra N104 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2015 - 2020
N SeriesRow-Crop tractor |
|---|---|
2015 - 2020 | |
N Series | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Valtra (a part of AGCO) |
Row-Crop tractor | |
Valtra N104 Engine | |
|---|---|
AGCO Power 4.4L 4-cyl diesel | |
Fuel tank | 62.1 gal
235.0 L |
83.2 galOptOptional
314.9 L | |
42.3 gal (steel tank)
160.1 L | |
Exhaust fluid (DEF) | 11.9 gal
45.0 L |
Engine details ...  | |
Valtra N104 Transmission | |
|---|---|
30-speed five-speed power shift | |
Transmission details ...  |
Valtra N104 Power | |
|---|---|
Engine | 103.3 hp
77.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with air-conditioning. |
Hydraulics | |
|---|---|
Type | open center |
closed center OptOptional | |
Rear valves | 2 to 5 |
Pump flow | 19.3 gpm (open)
73.1 lpm |
23.8 gpm (open option)
90.1 lpm | |
30.4 gpm (closed)
115.1 lpm | |
42.3 gpm (closed option)
160.1 lpm | |
52.8 gpm (closed option)
199.8 lpm | |
Tractor hitch | |
|---|---|
Rear lift | 14162 lbs
6423 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Front PTO | independent OptOptional |
Front PTO Type | 1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 104.9 inches
266 cm |
Weight | 11795 lbs
5350 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
N Series published in 2019, by Valtra |
Engine
Engine Detail — 268.4 ci / 4.4 L Diesel
Manufacturer | AGCO Power 44 AWF |
Configuration | turbocharged intercooled diesel, 4-cylinder, liquid-cooled |
Displacement | 268.4 ci
4.4 L |
Bore/Stroke | 4.25x4.72 inches
108 x 120 mm |
Emissions | Stage 4 |
Power | 103.3 hp
77.0 kW |
Maximum Power | 114 hp
85.0 kW |
Rated RPM | 2100 |
Torque | 346.7 lb-ft
470.1 Nm |
Torque RPM | 1500 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — Hi Tech
Transmission | Hi Tech |
Type | five-speed power shift |
Gears | 30 forward and reverse |
Dimensions
Valtra N104 Tires |
|---|
Dimensions | |
|---|---|
Wheelbase | 104.9 inches
266 cm |
Length | 183.3 inches
465 cm |
Height (cab) | 114.6 inches
291 cm |
Operating weight | 11795 lbs
5350 kg |
Max weight | 17637 lbs
8000 kg |
Ground clearance | 19.9 inches
50 cm |
