valtra s394
 | 2017 - 2025
Model year 2017-20182019-2025
S SeriesRow-Crop tractor | 2017 - 2025 | Model year 2017-20182019-2025 | S Series | Row-Crop tractor |
|---|---|---|---|---|---|
2017 - 2025 | |||||
Model year 2017-20182019-2025 | |||||
S Series | |||||
Row-Crop tractor | |||||
2017 - 2025 | |
|---|---|
Model year 2017-20182019-2025 | |
S Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Valtra (a part of AGCO) |
Row-Crop tractor | |
Valtra S394 Engine | |
|---|---|
AGCO Power 8.4L 6-cyl diesel | |
Fuel tank | 166.4 gal
629.8 L |
Exhaust fluid (DEF) | 15.9 gal
60.2 L |
Engine details ...  | |
Valtra S394 Transmission | |
|---|---|
continuously-variable transmission | |
Transmission details ...  |
Valtra S394 Power | |
|---|---|
Engine | 395 hp
294.6 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Power steering | |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Rear valves | 4 to 6 |
Front valves | 0 to 2 |
Pump flow | 54.2 gpm
205.1 lpm |
Tractor hitch | |
|---|---|
Rear Type | IV/III |
Rear lift | 26455 lbs
11999 kg |
Front lift | 11023 lbs
5000 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540E/1000 |
| 1000E/1000 |
Engine RPM | 540E@1600 |
| 1000E@1600 |
| 1000@2030 |
Dimensions & Tires | |
|---|---|
Wheelbase | 122.2 inches
310 cm |
Weight | 22708 lbs
10300 kg |
Front tire | 620/65R34 |
Rear tire | 710/75R42 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Battery volts | 12 |
References | |
|---|---|
 | |
S Series published in 2017, by Valtra |
