Versatile 2360

The Versatile 2360 is a tractor produced by Versatile. It is equipped with a 855 ci 14.0 L engine. The listed engine power is Diesel (listed): 360 hp / 268.5 kW. Transmission: QuadShift III. Operating weight: 30795 lbs 13968 kg.

Overview

	2002 - 2008 Four-wheel Drive (4WD) tractor

Production
Manufacturer	Versatile (a part of Buhler)
Four-wheel Drive (4WD) tractor
Built in Winnipeg, Manitoba, Canada

Variants
9684	similar New Holland model

Versatile 2360 Engine
Cummins 14.0L 6-cyl diesel
Engine details ...

Versatile 2360 Power
Engine	360 hp 268.5 kW
Drawbar (tested)	277.2 hp 206.7 kW
PTO (tested)	349.1 hp 260.3 kW
Performance test details ...

Mechanical
Four-wheel drive
Final drives	outboard planetary
Articulated power steering
Wet disc brakes
Cab standard with air-conditioning.

Hydraulics
Type	closed center load sensing
Pressure	2900 psi 200.0 bar
Valves	4
	5 (with 3-point hitch)
Total flow	50 gpm 189.2 lpm

Tractor hitch
Rear Type	4N/3
Rear lift	13000 lbs 5896 kg

Power Take-off (PTO)
Rear PTO	independent OptOptional
Clutch	electro-hydraulic wet disc
Rear PTO Type	1000 (1.75)

Dimensions & Tires
Wheelbase	133 inches 337 cm
Weight	30795 lbs 13968 kg
Front tire	20.8R42
Rear tire	20.8R42
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	130
Batteries	3
Battery CCA	950
Battery volts	12

References
Buhler Versatile 4WD published in 2001

Engine

Engine Detail — 855 ci / 14.0 L Diesel

Manufacturer	Cummins N14
Configuration	turbocharged diesel, 6-cylinder 24-valve, liquid-cooled inline
Displacement	855 ci 14.0 L
Bore/Stroke	5.50x6.00 inches 140 x 152 mm
Power	360 hp 268.5 kW
Compression	16.5:1
Rated RPM	2100
Starter volts	12

Transmission

Transmission options
12-speed partially synchronized
12-speed full power shift

Transmission — QuadShift III

Transmission	QuadShift III
Type	partially synchronized
Gears	12 forward and 4 reverse
Four synchronized gears in three ranges.

Transmission — 12 forward and 2 reverse full power shift

Type	full power shift
Gears	12 forward and 2 reverse

Dimensions

Versatile 2360 Tires
Ag front	20.8R42
Ag rear	20.8R42

Dimensions
Wheelbase	133 inches 337 cm
Length	266 inches 675 cm
Height	146.5 inches 372 cm
Weight	30795 lbs 13968 kg
Ground clearance	19.8 inches 50 cm

Tests

OCED Tractor Test 1942
Diesel 12-speed 4WD June 1 - July 31, 2000 Link: OCED Tractor Test 1942 file
PTO performance
Max power	349.1 hp 260.3 kW
Fuel use	18.5 gal/hour 70.0 l/hour
Power at rated engine speed	301.3 hp 224.7 kW
Fuel use	17.8 gal/hour 67.4 l/hour
Drawbar performance
Max power	277.2 hp 206.7 kW
Fuel use	17.8 gal/hour 67.4 l/hour
Max pull	31355 lbs 14222 kg

Photos

Versatile 260, left side.
