Versatile 256
The Versatile 256 is a tractor produced by Versatile. It is equipped with a 239 ci 3.9 L engine. The rated power output is 100.6 hp 75.0 kW. Transmission: infinite forward and reverse (3-range). Operating weight: 8700 to 11650 pounds.
Engine Power
100.6 hp
75.0 kW
Fuel & Capacities
39 gal
147.6 L
Transmission
infinite forward and reverse (3-range)
Operating Weight
11,650 lbs
5284 kg
Versatile 256 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1984 - 1985
200 Series |
|---|---|
1984 - 1985 | |
200 Series | |
Production | |
|---|---|
Manufacturer | Versatile |
Built in Winnipeg, Manitoba, Canada | |
Original price was $41,000 in 1985 | |
The Versatile 256 is a bi-directional tractor, designed to operate in both directions of travel. The operator console rotates 180-degrees. | |
Versatile 256 Engine | |
|---|---|
Cummins 3.9L 4-cyl diesel | |
Engine details ...  |
Versatile 256 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Versatile 256 Power | |
|---|---|
Engine | 100.6 hp
75.0 kW |
PTO (claimed) | 85.8 hp
64.0 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | power |
Hydraulic disc brakes | |
Cab standard with 180-degree console rotation. | |
Capacity | |
|---|---|
Fuel | 39 gal
147.6 L |
Hydraulic system | 8.5 gal
32.2 L |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Capacity | 8.5 gal
32.2 L |
Pressure | 2800 psi
193.1 bar |
Rear valves | 3 |
Front valves | 2 OptOptional |
Pump flow | 23 gpm
87.1 lpm |
Steering flow | 5 gpm
18.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | II/I OptOptional |
Control | position control |
Rear lift (at 24"/610mm) | 4400 lbs
1995 kg |
Front Hitch | II/I OptOptional |
Front lift (at ends) | 3266 lbs
1481 kg |
Front lift (at 24"/610mm) | 2000 lbs
907 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | wet disc |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@2500 |
1000@2500 | |
Front PTO | optional |
Front PTO Type | 540/1000 (1.375) |
Dimensions & Tires | |
|---|---|
Wheelbase | 86 inches
218 cm |
Weight | 8700 to 11650 pounds |
Front tire | 14.9x28 |
Rear tire | 14.9x28 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Batteries | 2 |
Battery CCA | 580 |
Battery volts | 12 |
References | |
|---|---|
 | |
200 Series published by Versatile | |
256 published by Versatile | |
Agricultural Operations Sales Manual published in 1983, by Versatile |
Engine
Engine Detail — 239 ci / 3.9 L Diesel
Manufacturer | Cummins 4BT 3.9 |
Configuration | turbocharged diesel, 4-cylinder, liquid-cooled |
Displacement | 239 ci
3.9 L |
Bore/Stroke | 4.016x4.724 inches
102 x 120 mm |
Power | 100.6 hp
75.0 kW |
Rated RPM | 2500 |
Torque | 250 lb-ft
339.0 Nm |
Torque RPM | 1600 |
Coolant capacity | 23.2 qts
22.0 L |
Transmission
Transmission — infinite forward and reverse (3-range) hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse (3-range) |
 | |
Dimensions
Versatile 256 Tires | |
|---|---|
Ag front | 14.9x28 |
Ag rear | 14.9x28 |
Ag front | 13.6x28 |
16.9x28 | |
Ag rear | 13.6x28 |
16.9x28 | |
Dimensions | |
|---|---|
Wheelbase | 86 inches
218 cm |
Height | 112 inches
284 cm |
Shipping weight | 8,700 lbs
3946 kg |
Operating weight | 11,650 lbs
5284 kg |
Photos
Versatile 256
Versatile 256
Versatile 256 with plow
