White FST-14

The White FST-14 is a tractor produced by White Lawn Tractors. It is equipped with a 480 cc 29.3 ci engine. The rated power output is 14 hp 10.4 kW. Transmission: CruiseMatic. Operating weight: 495 lbs 224 kg.

Overview

	1991 - 1993 Lawn tractor
1991 - 1993
Lawn tractor

Production
Manufacturer	White (a part of MTD)
Lawn tractor

White FST-14 Engine
14HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank	2.5 gal 9.5 L
Engine details ...

White FST-14 Transmission
7-speed CVT
Transmission details ...

Mechanical
Two-wheel drive
Manual four-wheel steering
Open operator station.

Power Take-off (PTO)
Mid PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	46 inches 116 cm
Weight	495 lbs 224 kg
Front tire	15x6.00
Rear tire	20x8.00
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	16
Battery CCA	275
Battery volts	12

References
4-Wheel Steering Lawn Tractor published in 1991, by White
Owner's Guide FST-14 (770-9080G) published in 1992
Owner's Guide FST-14 (770-8256H) published in 1993

Engine

Engine Detail — 480 cc / 29.3 ci Gasoline

Manufacturer	Briggs & Stratton Vanguard
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled vertical-shaft V-Twin
Displacement	480 cc 29.3 ci
Bore/Stroke	2.68x2.60 inches 68 x 66 mm
Power (gross)	14 hp 10.4 kW
Rated RPM	3600
Starter	electric
Starter volts	12

Transmission

Transmission — CruiseMatic

Transmission	CruiseMatic
Type	belt-driven CVT
Gears	7 forward and reverse

Dimensions

White FST-14 Tires
Lawn/turf front	15x6.00
Lawn/turf rear	20x8.00

Dimensions
Wheelbase	46 inches 116 cm
Length	64 inches 162 cm
Height (steering wheel)	41 inches 104 cm
Weight	495 lbs 224 kg

Attachments

Attachment overview
42" mid-mount mower deck
Snowblower
Blade

42" Mower deck
Type	mid-mount White
	2-blade with manual lift
Cutting width	42 inches 106 cm
Overall width	51 inches 129 cm
Cut height	1 to 4 inch 2 to 10 cm
Cut positions	5

Photos

White FST-14 cut-away diagram of four wheel steering system.
