Yanmar GT14
The Yanmar GT14 is a tractor produced by Yanmar Lawn Tractors. The listed engine power is Diesel (listed): 14 hp / 10.4 kW. Transmission: 6 forward and 3 reverse.
Engine Power
Diesel (listed): 14 hp / 10.4 kW
Fuel & Capacities
Diesel
Transmission
6 forward and 3 reverse
Overview
 | 1988 - 1990
Garden tractor |
|---|
Production | |
|---|---|
Manufacturer | Yanmar |
Garden tractor | |
Original price was $4663 in 1988 with 48-inch | |
Yanmar GT14 Engine | |
|---|---|
14HP Yanmar 2-cyl diesel | |
Engine details ...  |
Yanmar GT14 Transmission | |
|---|---|
6-speed power shift | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Tractor hitch | |
|---|---|
Rear Type | 0 OptOptional |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 2000 OptOptional |
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Full dimensions and tires ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
Engine
Engine Detail — Diesel
Manufacturer | Yanmar 2T75U |
Fuel Type | Diesel |
Configuration | 2-cylinder, liquid-cooled |
Power | 14 hp
10.4 kW |
Rated RPM | 2600 |
Starter | electric |
Starter volts | 12 |
Transmission
Transmission — 6 forward and 3 reverse power shift
Type | power shift |
Gears | 6 forward and 3 reverse |
Dimensions
Yanmar GT14 Tires |
|---|
Dimensions |
|---|
Attachments
Attachment overview | |
|---|---|
48" mid-mount mower deck | |
60" mid-mount mower deck | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
Photos
Yanmar GT14
Yanmar GT14
Yanmar GT14
Yanmar GT14 dashboard and controls.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Yanmar Lawn Tractors Yanmar GT14.
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Yanmar Lawn Tractors Yanmar GT14 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Yanmar Lawn Tractors Yanmar GT14.
Converted Equivalents:
Horsepower (HP)14 hp
Kilowatts (kW)10.4 kW
Metric Horsepower (PS / CV)14.2 PS
