Yanmar YM14

The Yanmar YM14 is a tractor produced by Yanmar Lawn Tractors. It is equipped with a 635 cc 38.8 ci engine. The listed engine power is Diesel (listed): 14 hp / 10.4 kW; Diesel (listed): 1.6 hp / 1.2 kW. Transmission: 6 forward and 3 reverse. Operating weight: 850 lbs 385 kg.

Overview

	1983 - 1989 Garden tractor

Production
Manufacturer	Yanmar
Garden tractor
Original price was $5,200 in 1983

Yanmar YM14 Engine
10.4KW Yanmar 635cc 2-cyl diesel
Engine details ...

Yanmar YM14 Transmission
6-speed power shift
Transmission details ...

Mechanical
Two-wheel drive
Differential lock	mechanical rear
Open operator station.

Tractor hitch
Rear Type	0

Power Take-off (PTO)
Rear PTO Type	2000

Dimensions & Tires
Weight	850 lbs 385 kg
Front tire	16x6.5-8
Rear tire	23x10.5-12
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Engine Detail — 635 cc / 38.8 ci Diesel

Manufacturer	Yanmar 2T75U-N
Fuel Type	Diesel
Configuration	2-cylinder, liquid-cooled
Displacement	635 cc 38.8 ci
Power	14 hp 10.4 kW
Pre-heating	glow plugs
Rated RPM	2600
Starter	electric
Starter volts	12
Starter power	1.6 hp 1.2 kW

Yanmar YM14 Engine
Image courtesy of Sorin Lungoci

Transmission

Transmission — 6 forward and 3 reverse power shift

Type	power shift
Gears	6 forward and 3 reverse
Two forward gears, plus reverse, on shift column with three ranges.

Dimensions

Yanmar YM14 Tires
Lawn/turf front	16x6.5-8
Lawn/turf rear	23x10.5-12

Dimensions
Weight	850 lbs 385 kg

Attachments

Attachment overview
121 cm mid-mount mower deck
152 cm mid-mount mower deck
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments.

Photos

Yanmar YM14

Yanmar YM14
