Zetor 7045

The Zetor 7045 is a tractor produced by Zetor. It is equipped with a 219.4 ci 3.6 L engine. The rated power output is 70 hp 52.2 kW. Transmission: 10 forward and 2 reverse. Operating weight: 7562 lbs 3430 kg.

Overview

	1980 - 1984 Utility tractor
1980 - 1984
Utility tractor

Production
Manufacturer	Zetor
Utility tractor
Built in Brno, Czechoslovakia

Variants
7011	2WD
7045	4WD

Zetor 7045 Engine
Zetor 3.6L 4-cyl diesel
Fuel tank	18.5 gal 70.0 L
Engine details ...

Zetor 7045 Transmission
10-speed partially-synchronized
Transmission details ...

Zetor 7045 Power
Engine	70 hp 52.2 kW
PTO (claimed)	60 hp 44.7 kW

Mechanical
Four-wheel drive
Steering	power assist
Drum brakes
Cab standard.

Hydraulics
Pressure	2321 psi 160.0 bar
Pump flow	5.3 gpm 20.1 lpm

Tractor hitch
Rear Type	II
Rear lift	3748 lbs 1700 kg

Power Take-off (PTO)
Rear PTO	live
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	87.4 inches 221 cm
Weight	7562 lbs 3430 kg
Front tire	10-24
Rear tire	14-30
Full dimensions and tires ...

Engine

Engine Detail — 219.4 ci / 3.6 L Diesel

Manufacturer	Zetor Z7001
Fuel Type	Diesel
Configuration	4-cylinder, liquid-cooled
Displacement	219.4 ci 3.6 L
Bore/Stroke	4.016x4.331 inches 102 x 110 mm
Power	70 hp 52.2 kW
Compression	17:1
Rated RPM	2200
Torque	147.5 lb-ft 200.0 Nm
Torque RPM	1600
Starter	electric
Starter volts	12

Transmission

Transmission — 10 forward and 2 reverse partially-synchronized

Type	partially-synchronized
Gears	10 forward and 2 reverse
Clutch	dry disc
Five gears (1-5) in two ranges (low-high). Synchronized shifting between gears 4 and 5.
With 14-30 rear tires.

Dimensions

Zetor 7045 Tires
Ag front	10-24
	11-24
Ag rear	14-30
	14-34
	12-36

Dimensions
Wheelbase	87.4 inches 221 cm
Length	146.5 inches 372 cm
Width	76.8 inches 195 cm
Height (cab)	96.5 inches 245 cm
Weight	7562 lbs 3430 kg
Ground clearance	14.4 inches 36 cm

Photos

Zetor 7045

Zetor 7045

Zetor 7045
