Zetor M50

The Zetor M50 is a tractor produced by Zetor. The listed engine power is Diesel (listed): 47.6 hp / 35.5 kW. Transmission: 16 forward and reverse.

Engine Power
Diesel (listed): 47.6 hp / 35.5 kW
Fuel & Capacities
Diesel
Transmission
16 forward and reverse

Overview

No photo available
2020 - M Compact SeriesCompact Utility tractor
2020 -
M Compact Series
Compact Utility tractor
Production
Manufacturer
Zetor
Compact Utility tractor
Zetor M50 Engine
Yanmar 4-cyl diesel
Engine details ...
Zetor M50 Transmission
16-speed shuttle
Transmission details ...
Zetor M50 Power
Engine
47.6 hp 35.5 kW
PTO (claimed)
40.5 hp 30.2 kW
Mechanical
Four-wheel drive
Power steering
Two-post folding ROPS.
Hydraulics
Pump flow
14.5 gpm 54.9 lpm
Tractor hitch
Rear lift
3314 lbs 1503 kg
Power Take-off (PTO)
Rear PTO
independent
Clutch
electro-hydraulic wet disc
Rear PTO Type
540 (1.375)
Dimensions & Tires
Full dimensions and tires ...
References
M50 references literature
M Series Product Guide published in 2020, by Zetor

Engine

Engine Detail — Diesel

Manufacturer
Yanmar
Fuel Type
Diesel
Configuration
4-cylinder, liquid-cooled
Power
47.6 hp 35.5 kW
Starter type
electric

Transmission

Transmission — 16 forward and reverse shuttle

Type
shuttle
Gears
16 forward and reverse

Dimensions

Zetor M50 Tires
Dimensions

Zetor M50 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Zetor M50.

Converted Equivalents:

Horsepower (HP)47.6 hp
Kilowatts (kW)35.5 kW
Metric Horsepower (PS / CV)48.3 PS
