Zetor M50

The Zetor M50 is a tractor produced by Zetor. The listed engine power is Diesel (listed): 47.6 hp / 35.5 kW. Transmission: 16 forward and reverse.

Engine Power
Diesel (listed): 47.6 hp / 35.5 kW
Fuel & Capacities
Diesel
Transmission
16 forward and reverse

Overview

No photo available
2020 - M Compact SeriesCompact Utility tractor
2020 -
M Compact Series
Compact Utility tractor
Production
Manufacturer
Zetor
Compact Utility tractor
Zetor M50 Engine
Yanmar 4-cyl diesel
Engine details ...
Zetor M50 Transmission
16-speed shuttle
Transmission details ...
Zetor M50 Power
Engine
47.6 hp 35.5 kW
PTO (claimed)
40.5 hp 30.2 kW
Mechanical
Four-wheel drive
Power steering
Two-post folding ROPS.
Hydraulics
Pump flow
14.5 gpm 54.9 lpm
Tractor hitch
Rear lift
3314 lbs 1503 kg
Power Take-off (PTO)
Rear PTO
independent
Clutch
electro-hydraulic wet disc
Rear PTO Type
540 (1.375)
Dimensions & Tires
Full dimensions and tires ...
References
M50 references literature
M Series Product Guide published in 2020, by Zetor

Engine

Engine Detail — Diesel

Manufacturer
Yanmar
Fuel Type
Diesel
Configuration
4-cylinder, liquid-cooled
Power
47.6 hp 35.5 kW
Starter type
electric

Transmission

Transmission — 16 forward and reverse shuttle

Type
shuttle
Gears
16 forward and reverse

Dimensions

Zetor M50 Tires
Dimensions

Recommended Implements & Sizing Guide

Engineering recommendations for Zetor M50 based on its 47.6 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm)Medium DutyStandard utility farm tillage.
Rotary Cutter / MowerMowing & Clearing
6 ft (72 in)1.8 mMedium DutyMedium pasture clearing; rear slip-clutch recommended.
Rotary TillerSeedbed Prep
66 to 72 in165 - 180 cmMedium DutyStandard utility tiller; slip clutch protection required.
Disc HarrowSecondary Tillage
7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙Medium DutyField leveling and clod breaking behind plows.
Hay BalerHay & Forage
Small Square Baler (14x18")小方捆打捆机 (36x46 cm)Medium DutyClassic 2-string baler for horse and small livestock hay.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Zetor M50.

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Zetor M50 Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Zetor M50.

Converted Equivalents:

Horsepower (HP)47.6 hp
Kilowatts (kW)35.5 kW
Metric Horsepower (PS / CV)48.3 PS

Direct Competitor Comparison

Compare Zetor M50 against same-era industry alternatives in the same horsepower class.

Current Model
Zetor

Zetor M50

Engine Power:Diesel (listed): 47.6 hp / 35.5 kW
★ Baseline Reference
DeereMarket Competitor

Deere 940

Engine Power:42.9
Production Years:1980 - 1986
Massey FergusonMarket Competitor

Massey Ferguson 140

Engine Power:43
Production Years:1966 - 1975
CaseIHMarket Competitor

CaseIH 385

Engine Power:43
Production Years:1985 - 1990
International HarvesterMarket Competitor

International Harvester 434

Engine Power:43
Production Years:1966 - 1972
