Agrinar T-160

The Agrinar T-160 is a tractor produced by Agrinar. It is equipped with a 408.9 ci 6.7 L engine. The rated power output is 161 hp 120.1 kW. Transmission: 12 forward and 4 reverse. Operating weight: 13,450 lbs 6100 kg.

Overview

Production
Manufacturer	Agrinar
Built in Santa Fe, Santa Fe, Argentina

Agrinar T-160 Engine
Fiat Powertrain Technologies (FPT) 6.7L 6-cyl diesel
Engine details ...

Agrinar T-160 Transmission
12-speed
Transmission details ...

Agrinar T-160 Power
Engine	161 hp 120.1 kW

Mechanical
Four-wheel drive
Steering	hydrostatic power
Wet disc brakes
Cab standard.

Capacity
Fuel	60.8 gal 230.1 L
Hydraulic system	26.4 gal 99.9 L

Hydraulics
Capacity	26.4 gal 99.9 L
Pressure	2857 psi 197.0 bar
Total flow	26.4 gpm 99.9 lpm

Power Take-off (PTO)
Rear PTO	indpendent
Rear PTO Type	540/1000

Dimensions & Tires
Weight	13,450 lbs 6100 kg
Front tire	14.9x26
Rear tire	24.5x32
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	130
Battery CCA	850
Battery volts	12

Engine

Engine Detail — 408.9 ci / 6.7 L Diesel

Configuration	turbocharged diesel, 6-cylinder, liquid-cooled
Fiat Powertrain Technologies (FPT) N67
Displacement	408.9 ci 6.7 L
Bore/Stroke	4.09x5.19 inches 104 x 132 mm
Power	161 hp 120.1 kW
Air cleaner	dual dry element
Rated RPM	2300
Torque	464.7 lb-ft 630.1 Nm
Torque RPM	1400
Starter volts	12
Oil capacity	19 qts 18.0 L
Coolant capacity	21.2 qts 20.1 L

Transmission

Transmission — 12 forward and 4 reverse

Gears	12 forward and 4 reverse
Clutch	dry disc
Oil capacity	45.4 qts 43.0 L
With 24.5x32 rear tires.

Dimensions

Agrinar T-160 Tires
Ag front	14.9x26
Ag rear	24.5x32

Dimensions
Weight	13,450 lbs 6100 kg

Photos

Agrinar T-160 tractor photo
