Allis Chalmers WC
The Allis Chalmers WC is a tractor produced by Allis Chalmers. It is equipped with a 201 ci 3.3 L engine. The rated power output is 25.45 hp 19.0 kW. Transmission: 4 forward and 1 reverse. Operating weight: 2700 to 3792 pounds.
Engine Power
25.45 hp
19.0 kW
Fuel & Capacities
Gasoline
Transmission
4 forward and 1 reverse
Operating Weight
2700 to 3792 pounds
Allis Chalmers WC Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1933 - 1948
Model year 1933-19371938-1948
Row-Crop tractor |
|---|---|
1933 - 1948 | |
Model year 1933-19371938-1948 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Allis Chalmers |
Row-Crop tractor | |
Built in West Allis, Wisconsin, USA | |
Total built | 178,202 |
The Allis-Chalmers WC was the first tractor tested on rubber tires at Nebraska. The WC was styled in 1938, starting at serial number WC74330. The styled WC featured a rounded radiator and larger tires. | |
Variants | |
|---|---|
WF | Standard front version (wide) |
Allis Chalmers WC Transmission | |
|---|---|
4-speed non-synchronized gear | |
Transmission details ...  |
Allis Chalmers WC Power | |
|---|---|
Drawbar (claimed) | 12 hp
8.9 kW |
Belt (claimed) | 21 hp
15.7 kW |
Plows | 2 |
Drawbar (tested) | 18.72 hp
14.0 kW |
Belt (tested) | 25.45 hp
19.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual |
Differential hand-operated mechanical drum brakes | |
Open operator station with steel pan seat. | |
Power Take-off (PTO) | |
|---|---|
Rear PTO | transmission |
Rear PTO Type | 535 |
Dimensions & Tires | |
|---|---|
Weight | 2700 to 3792 pounds |
Front tire | 24x4 |
Rear tire | 40x6 |
Full dimensions and tires ...  | |
Belt Pulley | |
|---|---|
Diameter | 9 inches
22 cm |
Width | 6.5 inches
16 cm |
RPM | 1170 |
Electrical | |
|---|---|
Charging system | generator |
Battery volts | 6 |
Battery AH | 95 |
References | |
|---|---|
 | |
Build a Better Farm published in 1940, by Allis Chalmers |
Engine
Engine options | |
|---|---|
Waukesha 3.0L 4-cyl gasoline | |
Allis-Chalmers 3.3L 4-cyl distillate | |
Allis-Chalmers 3.3L 4-cyl gasoline |
Engine Detail — 186 ci / 3.0 L Gasoline
Manufacturer | Waukesha |
Fuel Type | Gasoline |
Configuration | 4-cylinder, liquid-cooled |
Used on first 25 tractors built | |
Displacement | 186 ci
3.0 L |
Bore/Stroke | 3.625x4.50 inches
92 x 114 mm |
Starter type | manual crank |
Engine Detail — 201 ci / 3.3 L
Manufacturer | Allis-Chalmers |
Configuration | 4-cylinder, liquid-cooled vertical I-head |
distillate | |
Low-compression engine designed to operate on fuels rated at 30 octane or higher. | |
Displacement | 201 ci
3.3 L |
Bore/Stroke | 4.00x4.00 inches
102 x 102 mm |
Fuel use | 2.119 gal/hour
8.0 l/hour |
Air cleaner | oil bath |
Compression | 4.2:1 |
Rated RPM | 1300 |
Firing order | 1-2-4-3 |
Starter type | manual crank |
electric | |
Coolant capacity | 14 qts
13.2 L |
Sparkplug gap | 0.030 inches
0.762 mm |
Point gap | 0.020 inches
0.508 mm |
Intake valve clearance | 0.010 inches (hot)
0.254 mm |
Exhaust valve clearance | 0.010 inches (hot)
0.254 mm |
Oil capacity | 6 qts
5.7 L |
Engine Detail — 201 ci / 3.3 L Gasoline
Manufacturer | Allis-Chalmers |
Fuel Type | Gasoline |
Configuration | 4-cylinder, liquid-cooled vertical I-head |
Displacement | 201 ci
3.3 L |
Bore/Stroke | 4.00x4.00 inches
102 x 102 mm |
Fuel use | 2.861 gal/hour
10.8 l/hour |
Air cleaner | oil bath |
Compression | 5.0:1 |
Rated RPM | 1300 |
Firing order | 1-2-4-3 |
Starter type | manual crank |
electric | |
Coolant capacity | 14 qts
13.2 L |
Sparkplug gap | 0.030 inches
0.762 mm |
Point gap | 0.020 inches
0.508 mm |
Intake valve clearance | 0.010 inches (hot)
0.254 mm |
Exhaust valve clearance | 0.010 inches (hot)
0.254 mm |
Oil capacity | 6 qts
5.7 L |
Transmission
Transmission — 4 forward and 1 reverse non-synchronized gear
Type | non-synchronized gear | ||||
Gears | 4 forward and 1 reverse | ||||
Oil capacity | 4 qts
3.8 L | ||||
5 qts (with PTO)
4.7 L | |||||
Oil type | 32oF [0oC]↑ : SAE140 32oF [0oC]↓ : SAE90 | 32oF [0oC]↑ | : SAE140 | 32oF [0oC]↓ | : SAE90 |
32oF [0oC]↑ | : SAE140 | ||||
32oF [0oC]↓ | : SAE90 | ||||
Operated via gearshift lever and foot clutch. Fourth gear was not recommended for tractors equipped with steel wheels. | |||||
32oF [0oC]↑ | : SAE140 | ||||
32oF [0oC]↓ | : SAE90 | ||||
 | |||||
Dimensions
Allis Chalmers WC Tires | |
|---|---|
Ag front | 24x4 steel |
Ag rear | 40x6 steel |
Ag front | 5.25-17 |
Ag rear | 11.25x24 |
Dimensions | |
|---|---|
Length | 136 inches
345 cm |
Width | 76 inches
193 cm |
Height | 63 inches
160 cm |
Ground clearance | 29 inches (rear axle)
73 cm |
Rear tread | 65 to 76 inches
165 to 193 cm |
Allis Chalmers WC Weight | |
|---|---|
Shipping | 2,700 lbs (steel)
1224 kg |
3,300 lbs (rubber)
1496 kg | |
Operating | 3,190 lbs (steel)
1446 kg |
3,792 lbs (rubber)
1720 kg | |
Ballasted | 4,545 lbs
2061 kg |
Tests
Tractor Tests | |
|---|---|
NTTL 223: distillate 201 4-speed 2WD | |
NTTL 303: distillate 201 4-speed 2WD |
Nebraska Tractor Test 223 | |
|---|---|
Distillate 201 4-speed 2WD
May 2 - 16, 1934
Link: Nebraska Tractor Test 223 file | |
Belt power (max) | 21.48 hp
16.0 kW |
Belt fuel use (max) | 2.1 gal/hour
7.9 l/hour |
Drawbar performance | |
Max power | 14.36 hp (steel)
10.7 kW |
19.17 hp (rubber)
14.3 kW | |
Gear 2 (steel); 4 (rubber) used for power test. | |
Max pull | 1,921 lbs (steel)
871 kg |
1,735 lbs (rubber)
786 kg | |
Nebraska Tractor Test 303 | |
|---|---|
Distillate 201 4-speed 2WD
May 31 - June 14, 1938
Link: Nebraska Tractor Test 303 file | |
Belt power (max) | 25.45 hp
19.0 kW |
Belt fuel use (max) | 2.6 gal/hour
9.8 l/hour |
Drawbar performance | |
Max power | 18.72 hp (steel)
14.0 kW |
20.41 hp (rubber)
15.2 kW | |
Max pull | 2,599 lbs (steel)
1178 kg |
3,054 lbs (rubber)
1385 kg | |
Gear 1 used for pull test. | |
Photos
Unstyled Allis-Chalmers WC on steel.
Unstyled Allis-Chalmers WC with rubber tires.
Unstyled Allis-Chalmers WC with rubber tires.
Unstyled Allis-Chalmers WC with rubber tires.
Unstyled Allis-Chalmers WC with rubber tires.
Unstyled Allis-Chalmers WC controls and operator station.
Unstyled Allis-Chalmers WC with single front wheel.
Unstyled Allis-Chalmers WC with single front wheel.
