Antonio Carraro TTR 3800

The Antonio Carraro TTR 3800 is a tractor produced by Antonio Carraro. It is equipped with a 94.7 ci 1.6 L engine. The listed engine power is Diesel (listed): 36 hp / 26.8 kW. Transmission: infinite forward and reverse. Operating weight: 2150 lbs 975 kg.

Engine Power

Diesel (listed): 36 hp / 26.8 kW

Fuel & Capacities

7.9 gal 29.9 L

Transmission

infinite forward and reverse

Operating Weight

2150 lbs 975 kg

Overview

Production
Manufacturer	Antonio Carraro

Antonio Carraro TTR 3800 Engine
Lombardini 1.6L 3-cyl diesel
Fuel tank	7.9 gal 29.9 L
Engine details ...

Antonio Carraro TTR 3800 Transmission
hydroastatic
Transmission details ...

Antonio Carraro TTR 3800 Power
Engine	36 hp 26.8 kW

Mechanical
Four-wheel drive
Articulated power steering
Mechanical drum brakes
Two-post fixed ROPS.

Tractor hitch
Rear Type	I
Rear lift	4078.6 lbs 1850 kg
Front Hitch	I OptOptional
Front lift	882 lbs 400 kg

Power Take-off (PTO)
Rear PTO Type	540/1000 (1.375)

Dimensions & Tires
Wheelbase	51.2 inches 130 cm
Weight	2150 lbs 975 kg
Front tire	6.50x16
Rear tire	6.50x16
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

Engine

Engine Detail — 94.7 ci / 1.6 L Diesel

Manufacturer	Lombardini 1503
Fuel Type	Diesel
Configuration	3-cylinder, liquid-cooled
Displacement	94.7 ci 1.6 L
Bore/Stroke	3.46x3.35 inches 88 x 85 mm
Power	36 hp 26.8 kW
Starter	electric
Starter volts	12

Transmission

Transmission — infinite forward and reverse hydroastatic

Type	hydroastatic
Gears	infinite forward and reverse

Dimensions

Antonio Carraro TTR 3800 Tires
Ag front	6.50x16
Ag rear	6.50x16

Dimensions
Wheelbase	51.2 inches 130 cm
Weight	2150 lbs 975 kg

Photos

Antonio Carraro TTR 3800

Recommended Implements & Sizing Guide

Engineering recommendations for Antonio Carraro TTR 3800 based on its 36 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	2 to 3 Bottom (14-16")2 - 3 铧 (35-40 cm)	Medium Duty	Standard utility farm tillage.
Rotary Cutter / MowerMowing & Clearing	5 ft (60 in)1.5 m	Medium Duty	Pasture maintenance and weeds up to 1.5" diameter.
Rotary TillerSeedbed Prep	54 to 60 in135 - 150 cm	Medium Duty	Thorough seedbed preparation in orchards and vegetable plots.
Disc HarrowSecondary Tillage	5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片)	Light Duty	Small acreage soil break-up and secondary aeration.
Hay BalerHay & Forage	Small Square Baler (14x18")小方捆打捆机 (36x46 cm)	Medium Duty	Classic 2-string baler for horse and small livestock hay.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Antonio Carraro TTR 3800.

Estimated Continuous Field Runtime: 4.2 hrs

Approximately 4.2 hours of continuous field operation at ~75% rated power on a full tank (7.9 gal / 29.9 L).

Estimated 75% Load Fuel Burn~1.9 gal/hr (7.1 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours
