Bad Boy 1022
The Bad Boy 1022 is a tractor produced by Bad Boy. It is equipped with a 60.6 ci 1.0 L engine. The listed engine power is Diesel (gross): 21.5 hp / 16.0 kW. Transmission: infinite forward and reverse (2-range). Operating weight: 747 lbs 338 kg.
Engine Power
Diesel (gross): 21.5 hp / 16.0 kW
Fuel & Capacities
6.6 gal
25.0 L
Transmission
infinite forward and reverse (2-range)
Operating Weight
747 lbs
338 kg
Overview
 | 2021 -
10 SeriesSub-Compact Utility tractorTYM built |
|---|---|
2021 - | |
10 Series | |
Sub-Compact Utility tractor | |
TYM built | |
2021 - | |
|---|---|
10 Series | |
Sub-Compact Utility tractor | |
TYM built |
Production | |
|---|---|
Distributor | Bad Boy |
Manufacturer | TYM |
Sub-Compact Utility tractor | |
Bad Boy 1022 Engine | |
|---|---|
Yanmar 1.0L 3-cyl diesel | |
Engine details ...  |
Bad Boy 1022 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Bad Boy 1022 Power | |
|---|---|
Engine (gross) | 21.5 hp
16.0 kW |
PTO (claimed) | 15.4 hp
11.5 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Two-post folding ROPS. | |
Capacity | |
|---|---|
Fuel | 6.6 gal
25.0 L |
Hydraulic system | 3.6 gal
13.6 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 3.6 gal
13.6 L |
Pump flow | 4.2 gpm
15.9 lpm |
Total flow | 6.3 gpm
23.8 lpm |
Steering flow | 2.1 gpm
7.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | IN |
Control | position control |
Rear lift (at 24"/610mm) | 499 lbs
226 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@3200 |
Mid PTO | independent OptOptional |
Engine RPM | 2500@3200 |
Dimensions & Tires | |
|---|---|
Wheelbase | 53.1 inches
134 cm |
Weight | 1433 lbs
650 kg |
Front tire | 16x7.50-9 |
Rear tire | 24x12.00-12 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 40 |
Battery CCA | 500 |
Battery volts | 12 |
References | |
|---|---|
 | |
Tractor Series published in 2021, by Bad Boy | |
Tractor Series published in 2023, by Bad Boy | |
Mow with an Attitude published in 2024, by Bad Boy | |
 | |
Operator's Manual Model BBH100 Backhoe published in 2022 | |
Operator's Manual BBL100 Front End Loader published in 2022 | |
Operator's Manual Model 1022H published in 2022 |
Engine
| 2021 -
10 SeriesSub-Compact Utility tractorTYM built |
|---|---|
2021 - | |
10 Series | |
Sub-Compact Utility tractor | |
TYM built | |
2021 - | |
|---|---|
10 Series | |
Sub-Compact Utility tractor | |
TYM built |
Engine Detail — 60.6 ci / 1.0 L Diesel
Manufacturer | Yanmar 3TNM74F |
Fuel Type | Diesel |
Configuration | 3-cylinder, liquid-cooled inline |
Displacement | 60.6 ci
1.0 L |
Bore/Stroke | 2.91x3.03 inches
74 x 77 mm |
Power (gross) | 21.5 hp
16.0 kW |
Fuel system | indirect injection |
Air cleaner | dry |
Rated RPM | 3200 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 2.11 qts
2.0 L |
Coolant capacity | 3.7 qts
3.5 L |
Bad Boy 1022 Engine | |
|---|---|
 |
Transmission
| 2021 -
10 SeriesSub-Compact Utility tractorTYM built |
|---|---|
2021 - | |
10 Series | |
Sub-Compact Utility tractor | |
TYM built | |
2021 - | |
|---|---|
10 Series | |
Sub-Compact Utility tractor | |
TYM built |
Transmission — infinite forward and reverse (2-range) hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse (2-range) |
Oil capacity | 14.2 qts
13.4 L |
 | |
Dimensions
| 2021 -
10 SeriesSub-Compact Utility tractorTYM built |
|---|---|
2021 - | |
10 Series | |
Sub-Compact Utility tractor | |
TYM built | |
2021 - | |
|---|---|
10 Series | |
Sub-Compact Utility tractor | |
TYM built |
Bad Boy 1022 Tires | |
|---|---|
Standard tires (ag) | Front: 16x7.50-9. Rear: 24x12.00-12 |
Industrial front | 16x7.50-8 |
Industrial rear | 16x12.00-12 |
Dimensions | |
|---|---|
Wheelbase | 53.1 inches
134 cm |
Length | 94.2 inches
239 cm |
Width | 44.5 inches
113 cm |
Height (ROPS) | 86.6 inches
219 cm |
Weight | 1433 lbs
650 kg |
Ground clearance | 8.3 inches
21 cm |
Attachments
| 2021 -
10 SeriesSub-Compact Utility tractorTYM built |
|---|---|
2021 - | |
10 Series | |
Sub-Compact Utility tractor | |
TYM built | |
2021 - | |
|---|---|
10 Series | |
Sub-Compact Utility tractor | |
TYM built |
Attachment overview | |
|---|---|
Front-end loader | |
Backhoe |
Bad Boy BBH100 Backhoe | |
|---|---|
Backhoe type | Bad Boy BBH100 Backhoe |
Weight | 747 lbs
338 kg |
Transport height | 60.8 inches
154 cm |
Bucket width | 12 inches
30 cm |
2-Foot flat digging depth | 66.5 inches
168 cm |
Reach from pivot | 89.7 inches
227 cm |
Loading height | 60.8 inches
154 cm |
Bucket Rotation | 169° |
Swing Arc | 140° |
Bucket force | 1975 lbs
895 kg |
Photos
Bad Boy 1022 tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Bad Boy 1022 based on its 21.5 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 1 to 2 Bottom (12")1 - 2 铧 (30 cm) | Light Duty | Ideal for garden plots and light sandy soil. |
Rotary Cutter / MowerMowing & Clearing | 4 ft (48 in)1.2 m | Light Duty | Pasture clipping and light brush under 1" diameter. |
Rotary TillerSeedbed Prep | 42 to 48 in105 - 120 cm | Light Duty | Covers compact tractor tire width. |
Disc HarrowSecondary Tillage | 5 to 6 ft (16-18" discs)1.5 - 1.8 m (40-45 cm 耙片) | Light Duty | Small acreage soil break-up and secondary aeration. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Bad Boy 1022.
Estimated Continuous Field Runtime: 5.9 hrs
Approximately 5.9 hours of continuous field operation at ~75% rated power on a full tank (6.6 gal / 25 L).
Estimated 75% Load Fuel Burn~1.1 gal/hr (4.2 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Bad Boy 1022 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Bad Boy 1022.
Converted Equivalents:
Horsepower (HP)21.5 hp
Kilowatts (kW)16 kW
Metric Horsepower (PS / CV)21.8 PS
