Captain 250 DI

The Captain 250 DI is a tractor produced by Captain. It is equipped with a 78.7 ci 1.3 L engine. The rated power output is 25 hp 18.6 kW. Transmission: 8 forward and 2 reverse. Operating weight: 1962 to 2083 pounds.

Overview

	2014 - Compact Utility tractor
2014 -
Compact Utility tractor

Production
Manufacturer	Captain
Compact Utility tractor
Built in Rajkot, India

Captain 250 DI Engine
1.3L 2-cyl diesel
Engine details ...

Captain 250 DI Transmission
8-speed partially synchronized
Transmission details ...

Captain 250 DI Power
Engine	25 hp 18.6 kW

Mechanical
Two- or four-wheel drive
Mechanical drum brakes
Open operator station.

Power Take-off (PTO)
Rear PTO Type	540 (1.375)

Dimensions & Tires
Wheelbase	61 inches 154 cm
Weight	1962 to 2083 pounds
Front tire	5.20-14
2WD Rear tire	8.00-18
Full dimensions and tires ...

Electrical
Ground	negative
Battery volts	12

References
10-30 HP Small Tractors Series - 7G published in 2016, by Captain

Engine

Engine Detail — 78.7 ci / 1.3 L Diesel

Fuel Type	Diesel
Configuration	2-cylinder, liquid-cooled
Displacement	78.7 ci 1.3 L
Bore/Stroke	3.74x3.58 inches 95 x 91 mm
Power	25 hp 18.6 kW
Rated RPM	2200
Starter	electric
Starter volts	12

Transmission

Transmission — 8 forward and 2 reverse partially synchronized

Type	partially synchronized
Gears	8 forward and 2 reverse
Four gears, plus reverse, in two ranges.

Dimensions

Captain 250 DI Tires
2WD Standard tires (ag)	Front: 5.20-14. Rear: 8.00-18
4WD Standard tires (ag)	Front: 5.00-12. Rear: 8.00-18

Dimensions
Wheelbase	61 inches 154 cm
Length	103.4 inches 262 cm
Width	40.9 inches 103 cm
Height (exhaust)	66.9 inches 169 cm
2WD Weight	1962 lbs 889 kg
4WD Weight	2083 lbs 944 kg

Photos

Captain 250 DI tractor photo
