CaseIH 4694
The CaseIH 4694 is a tractor produced by Caseih. It is equipped with a 504 ci 8.3 L engine. The listed engine power is Diesel (listed): 261 hp / 194.6 kW. Transmission: 12 forward and 4 reverse. Drive type: 4x4 4WD. Operating weight: 22,310 lbs 10119 kg.
Engine Power
Diesel (listed): 261 hp / 194.6 kW
Drive & Traction
4x4 4WD
Fuel & Capacities
128 gal
484.5 L
Transmission
12 forward and 4 reverse
Operating Weight
22,310 lbs (with 20.8-34 duals)
10119 kg
Overview
 | 1984 - 1987
4WD 94 SeriesFour-wheel Drive (4WD) tractor
4WD 94 Series
Four-wheel Drive (4WD) tractor |
|---|
Production | |
|---|---|
Manufacturer | CaseIH |
Four-wheel Drive (4WD) tractor | |
Built in Racine, Wisconsin, USA | |
Original price | $81,000 (1987) |
CaseIH 4694 Engine | |
|---|---|
Case 8.3L 6-cyl diesel | |
Engine details ...  |
CaseIH 4694 Transmission | |
|---|---|
12-speed partial power shift | |
Transmission details ...  |
CaseIH 4694 Power | |
|---|---|
Engine | 261 hp
194.6 kW |
PTO (claimed) | 219 hp
163.3 kW |
Drawbar (tested) | 189.75 hp
141.5 kW |
PTO (tested) | 219.62 hp
163.8 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Drive | 4x4 4WD |
Steering | hydraulic, front, rear or four-wheel crab steering |
Hydraulic dry disc brakes | |
Silent Guardian cab standard. | |
Capacity | |
|---|---|
Fuel | 128 gal
484.5 L |
Hydraulic system | 15.5 gal
58.7 L |
Hydraulics | |
|---|---|
Type | closed center |
Capacity | 15.5 gal
58.7 L |
Pressure | 2350 psi
162.0 bar |
Valves | 2 to 4 |
Total flow | 31 gpm
117.3 lpm |
Tractor hitch | |
|---|---|
Rear Type | III (optional) |
Rear lift (at 24"/610mm) | 12,750 lbs
5783 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent (optional) |
Rear PTO Type | 1000 |
Engine RPM | 1000@2200 |
Dimensions & Tires | |
|---|---|
Wheelbase | 102 inches
259 cm |
Weight | 22,310 lbs
10119 kg |
Front tire | 18.4-34 |
Rear tire | 18.4-34 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
4-Wheel Drive Tractors published in 1987, by CaseIH | |
1985 Farm Equipment Buyer's Guide published by CaseIH |
Engine
Engine Detail — 504 ci / 8.3 L Diesel
Manufacturer | Case |
Configuration | turbocharged intercooled diesel, 6-cylinder, liquid-cooled |
Displacement | 504 ci
8.3 L |
Bore/Stroke | 4.625x5.00 inches
117 x 127 mm |
Power | 261 hp
194.6 kW |
Air cleaner | dual paper elements |
Compression | 15.8:1 |
Rated RPM | 2200 |
Torque | 680 lb-ft
922.1 Nm |
Torque RPM | 1650 |
Starter volts | 12 |
Oil capacity | 24 qts
22.7 L |
Coolant capacity | 48 qts
45.4 L |
Transmission
Transmission — 12 forward and 4 reverse partial power shift
Type | partial power shift |
Gears | 12 forward and 4 reverse |
Clutch | hydraulic wet disc |
Four ranges (1-4) with three power shift gears (1-3) plus reverse in each range. Both shift levers mounted on the dashboard. Range shift lever is to the left in a H-pattern. Gear shift is an inline pattern on the right. | |
With 23.1x30 tires. | |
 | |
Dimensions
CaseIH 4694 Tires | |
|---|---|
Ag front | 18.4-34 |
Ag rear | 18.4-34 |
Dimensions | |
|---|---|
Wheelbase | 102 inches
259 cm |
Length | 225 inches
571 cm |
Width | 96 inches (minimum)
243 cm |
143 inches (duals)
363 cm | |
Height (exhaust) | 125 inches
317 cm |
Operating weight | 22,310 lbs (with 20.8-34 duals)
10119 kg |
Ballasted weight | 25,230 lbs
11444 kg |
Ground clearance | 18 inches (frame)
45 cm |
Front tread | 76 to 139 inches
193 to 353 cm |
Rear tread | 76 to 139 inches
193 to 353 cm |
Tests
Nebraska Tractor Test 1329 | |
|---|---|
Diesel 12-speed 4WD
October 18 - 26, 1979
Link: Nebraska Tractor Test 1329 file | |
PTO performance | |
Power at rated engine speed | 219.62 hp
163.8 kW |
Fuel use | 14.4 gal/hour
54.5 l/hour |
Drawbar performance | |
Max power | 189.75 hp
141.5 kW |
Fuel use | 14.2 gal/hour
53.7 l/hour |
Gear 3-2 used for power test. | |
Max pull | 24,564 lbs
11142 kg |
Gear 1-2 used for pull test. | |
Photos
CaseIH 4694
CaseIH 4694
Case IH 4694, rear view.
Recommended Implements & Sizing Guide
Engineering recommendations for Caseih 4694 based on its 261 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 8+ Bottom On-Land Hitch8+ 铧重型机外牵引犁 | Commercial / Field Scale | High horsepower articulated/4WD field plowing. |
Rotary Cutter / MowerMowing & Clearing | 15 to 20 ft Batwing4.6 - 6.1 m 宽幅折叠翼 | Commercial / Field Scale | Large commercial field and roadside mowing operations. |
Rotary TillerSeedbed Prep | 90 to 120 in Heavy Duty230 - 300 cm 重型旋耕机 | Commercial / Field Scale | Deep intensive seedbed preparation for commercial row crops. |
Disc HarrowSecondary Tillage | 24 to 36 ft Heavy Duty Field Disc7.3 - 11.0 m 超宽重型整地耙 | Commercial / Field Scale | Broad-acre grain tillage for high-drawbar tractors. |
Hay BalerHay & Forage | Large Square Baler (3x4 or 4x4)大方捆商用打捆机 (1.2x1.2 m) | Commercial / Field Scale | High-capacity commercial forage harvesting (1000 RPM PTO). |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Caseih 4694.
Estimated Continuous Field Runtime: 9.4 hrs
Approximately 9.4 hours of continuous field operation at ~75% rated power on a full tank (128 gal / 484.5 L).
Estimated 75% Load Fuel Burn~13.6 gal/hr (51.4 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Caseih 4694 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Caseih 4694.
Converted Equivalents:
Horsepower (HP)261 hp
Kilowatts (kW)194.6 kW
Metric Horsepower (PS / CV)264.6 PS
Direct Competitor Comparison
Compare CaseIH 4694 against same-era industry alternatives in the same horsepower class.
Current Model
Caseih
CaseIH 4694
Engine Power:Diesel (listed): 261 hp / 194.6 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester 7488
Engine Power:235
Production Years:1985 - 1985
