CaseIH 9190
The CaseIH 9190 is a tractor produced by Caseih. It is equipped with a 1150 ci 18.8 L engine. The rated power output is 525 hp 391.5 kW. Transmission: 24 forward and 4 reverse. Operating weight: 40720 lbs 18470 kg.
Engine Power
525 hp
391.5 kW
Fuel & Capacities
385 gal
1457.2 L
Transmission
24 forward and 4 reverse
Operating Weight
40720 lbs
18470 kg
Caseih 9190 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1987
9100 SeriesFour-wheel Drive (4WD) tractor |
|---|---|
1987 | |
9100 Series | |
Four-wheel Drive (4WD) tractor | |
Production | |
|---|---|
Manufacturer | CaseIH |
Four-wheel Drive (4WD) tractor | |
Built in Fargo, North Dakota, USA | |
Original price was $191,000 in 1987 | |
CaseIH 9190 Engine | |
|---|---|
Cummins 18.8L 6-cyl diesel | |
Engine details ...  |
CaseIH 9190 Transmission | |
|---|---|
24-speed six-speed power shift | |
Transmission details ...  |
CaseIH 9190 Power | |
|---|---|
Engine | 525 hp
391.5 kW |
Drawbar (claimed) | 420 hp
313.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | hydrostatic power articulated |
Disc brakes | |
Cab standard with air-conditioning and AM/FM cassette radio. | |
Capacity | |
|---|---|
Fuel | 385 gal
1457.2 L |
Hydraulic system | 26 gal
98.4 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 26 gal
98.4 L |
Pressure | 2250 psi
155.1 bar |
Valves | 4 or 5 |
Total flow | 38 gpm
143.8 lpm |
Dimensions & Tires | |
|---|---|
Wheelbase | 150 inches
381 cm |
Weight | 40720 lbs
18470 kg |
Front tire | 30.5-32 |
Rear tire | 30.5-32 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
References | |
|---|---|
 | |
4-Wheel Drive Tractors published in 1987, by CaseIH |
Engine
Engine Detail — 1150 ci / 18.8 L Diesel
Manufacturer | Cummins KTA-1150 |
Configuration | turbocharged aftercooled diesel, 6-cylinder, liquid-cooled inline |
Displacement | 1150 ci
18.8 L |
Bore/Stroke | 6.25x6.25 inches
159 x 159 mm |
Power | 525 hp
391.5 kW |
Rated RPM | 2100 |
Torque | 1575 lb-ft
2135.7 Nm |
Torque RPM | 1500 |
Oil capacity | 76 qts
71.9 L |
Coolant capacity | 112 qts
106.0 L |
Transmission
Transmission — 24 forward and 4 reverse six-speed power shift
Manufacturer | Allison |
Type | six-speed power shift |
Gears | 24 forward and 4 reverse |
Six gears (1-6) plus reverse in four ranges. | |
With 30.5x32 rear tires. | |
 | |
Dimensions
CaseIH 9190 Tires | |
|---|---|
Ag front | 30.5-32 |
Ag rear | 30.5-32 |
Dimensions | |
|---|---|
Wheelbase | 150 inches
381 cm |
Length | 290 inches
736 cm |
Width | 119 inches (minimum)
302 cm |
190.8 inches (duals)
484 cm | |
Height (exhaust) | 161 inches
408 cm |
Weight | 40720 lbs
18470 kg |
Ground clearance | 23.4 inches (frame)
59 cm |
Photos
CaseIH 9190 tractor photo
