CaseIH JX1060C

The CaseIH JX1060C is a tractor produced by Caseih. It is equipped with a 178.8 ci 2.9 L engine. The listed engine power is Diesel (gross): 57 hp / 42.5 kW. Transmission: 16 forward and reverse. Operating weight: 6065 to 6590 pounds.

Engine Power
Diesel (gross): 57 hp / 42.5 kW
Fuel & Capacities
19.5 gal 73.8 L
Transmission
16 forward and reverse
Operating Weight
6065 to 6590 pounds

Overview

CaseIH JX1060C tractor photo
2004 - 2008 JXC SeriesUtility tractor JXC Series Utility tractor
Production
Manufacturer
CaseIH
Utility tractor
Built in Jesi, Italy
CaseIH JX1060C Engine
Iveco 2.9L 3-cyl diesel
Fuel tank
19.5 gal 73.8 L
Engine details ...
CaseIH JX1060C Power
Engine (gross)
57 hp 42.5 kW
PTO (claimed)
45 hp 33.6 kW
Drawbar (tested)
38.4 hp 28.6 kW
PTO (tested)
48.3 hp 36.0 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Cab optional.
Hydraulics
Type
open center
Pressure
2755 psi 190.0 bar
Valves
1 to 4
Pump flow
12.4 gpm 46.9 lpm
16.9 gpm*Standard with cab, optional with ROPS. 64.0 lpm
Steering flow
7.4 gpm 28.0 lpm
9.4 gpm*Standard with cab, optional with ROPS. 35.6 lpm
Tractor hitch
Rear Type
II
Control
mechanical lower-link draft sensing.
Rear lift
3960 lbs 1796 kg
Power Take-off (PTO)
Rear PTO
independent
Clutch
mechanical dry disc
Rear PTO Type
540 (1.375)
Dimensions & Tires
2WD Wheelbase
83.9 inches 213 cm
4WD Wheelbase
81.3 inches 206 cm
Weight
6065 to 6590 pounds
Full dimensions and tires ...
Electrical
Ground
negative
Charging system
alternator
ROPS Charging amps
65
Cab Charging amps
85
Battery CCA
730
Battery volts
12

Engine

Engine Detail — 178.8 ci / 2.9 L Diesel

Manufacturer
Iveco
Fuel Type
Diesel
Configuration
3-cylinder, liquid-cooled
Displacement
178.8 ci 2.9 L
Bore/Stroke
4.094x4.528 inches 104 x 115 mm
Power (gross)
57 hp 42.5 kW
Fuel system
direct injection
Air cleaner
dual paper elements
Pre-heating
thermostart
Compression
18.0:1
Rated RPM
2300
Starter volts
12

Transmission

Transmission options
16-speed mechanical shuttle
16-speed power shuttle

Transmission — 16 forward and reverse mechanical shuttle

Type
mechanical shuttle
Gears
16 forward and reverse
JX1060C mechanical shuttle speeds

Transmission — 16 forward and reverse power shuttle

Type
power shuttle
Gears
16 forward and reverse

Dimensions

CaseIH JX1060C Tires
Dimensions
2WD Wheelbase
83.9 inches 213 cm
4WD Wheelbase
81.3 inches 206 cm
2WD Length
155.7 inches 395 cm
4WD Length
154 inches 391 cm
Width
69.6 inches*Minimum width. 176 cm
CaseIH JX1060C Weight
Operating
6,065 lbs (2WD) 2751 kg
6,590 lbs (4WD) 2989 kg
Ballasted
7,670 lbs 3479 kg
CaseIH JX1060C Height
ROPS
95.6 inches 242 cm
75.6 inches (lowered) 192 cm
Cab
91.5 inches 232 cm

Tests

OCED Tractor Test 2156
Diesel 16-speed 4WD March 1 - 31, 2004 Link: OCED Tractor Test 2156 file
PTO performance
Max power
48.3 hp 36.0 kW
Fuel use
3.0 gal/hour 11.4 l/hour
Power at rated engine speed
47.2 hp 35.2 kW
Fuel use
3.0 gal/hour 11.4 l/hour
Power at rated PTO speed
47.3 hp 35.3 kW
Fuel use
3.0 gal/hour 11.4 l/hour
Drawbar performance
Max power
38.4 hp 28.6 kW
Fuel use
3.0 gal/hour 11.4 l/hour
Gear 9 used for power test.

Photos

CaseIH JX1060C tractor photo

CaseIH JX1060C tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Caseih JX1060C based on its 57 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
3 to 4 Bottom (16")3 - 4 铧 (40 cm)Heavy DutySuitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing
6 ft (72 in)1.8 mMedium DutyMedium pasture clearing; rear slip-clutch recommended.
Rotary TillerSeedbed Prep
66 to 72 in165 - 180 cmMedium DutyStandard utility tiller; slip clutch protection required.
Disc HarrowSecondary Tillage
7 to 8 ft Tandem Disc2.1 - 2.4 m 对开双排耙Medium DutyField leveling and clod breaking behind plows.
Hay BalerHay & Forage
Small Square Baler (14x18")小方捆打捆机 (36x46 cm)Medium DutyClassic 2-string baler for horse and small livestock hay.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Caseih JX1060C.

Estimated Continuous Field Runtime: 6.6 hrs

Approximately 6.6 hours of continuous field operation at ~75% rated power on a full tank (19.5 gal / 73.8 L).

Estimated 75% Load Fuel Burn~3 gal/hr (11.2 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Caseih JX1060C Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Caseih JX1060C.

Converted Equivalents:

Horsepower (HP)57 hp
Kilowatts (kW)42.5 kW
Metric Horsepower (PS / CV)57.8 PS
