CaseIH JX90U

The CaseIH JX90U is a tractor produced by Caseih. It is equipped with a 238.5 ci 3.9 L engine. The listed engine power is Diesel (gross): 84 hp / 62.6 kW. Transmission: 20 forward and 12 reverse. Operating weight: 8070 to 8710 pounds.

Engine Power
Diesel (gross): 84 hp / 62.6 kW
Fuel & Capacities
33.5 gal 126.8 L
Transmission
20 forward and 12 reverse
Operating Weight
8070 to 8710 pounds

Overview

CaseIH JX90U tractor photo
2002 - 2003 JXU Maxxima SeriesUtility tractor JXU Maxxima Series Utility tractor
Production
Manufacturer
CaseIH
Utility tractor
Built in Italy
CaseIH JX90U Engine
Iveco 3.9L 4-cyl diesel
Fuel tank
33.5 gal 126.8 L
Engine details ...
CaseIH JX90U Power
Engine (gross)
84 hp 62.6 kW
PTO (claimed)
76 hp 56.7 kW
Drawbar (tested)
65.4 hp 48.8 kW
PTO (tested)
78.0 hp 58.2 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Independent hydraulic wet disc brakes
Two-post folding ROPS. Cab optional.
Hydraulics
Type
open center
Valves
2 or 3
Pump flow
14.5 gpm 54.9 lpm
Total flow
20 gpm 75.7 lpm
Steering flow
5.5 gpm 20.8 lpm
Tractor hitch
Rear Type
II
Control
mechanical lower-link draft sensing
Rear lift
7900 lbs 3583 kg
Power Take-off (PTO)
Rear PTO
independent
Clutch
electro-hydraulic wet disc
Rear PTO Type
540/1000
Dimensions & Tires
2WD Wheelbase
92.2 inches 234 cm
4WD Wheelbase
91.1 inches 231 cm
Weight
8070 to 8710 pounds
Full dimensions and tires ...
Electrical
Charging system
alternator
Charging amps
85
Battery CCA
960

Engine

Engine Detail — 238.5 ci / 3.9 L Diesel

Manufacturer
Iveco
Configuration
turbocharged diesel, 4-cylinder, liquid-cooled
Displacement
238.5 ci 3.9 L
Bore/Stroke
4.094x4.528 inches 104 x 115 mm
Power (gross)
84 hp 62.6 kW
Fuel system
mechanical direct injection
Air cleaner
dual paper elements
Pre-heating
thermostart
Compression
16.5:1
Rated RPM
2500
Starter volts
12

Transmission

Transmission options
24-speed two-speed power shift
24-speed power shuttle
20-speed syncromesh

Transmission — 24 forward and 12 reverse two-speed power shift

Type
two-speed power shift
Gears
24 forward and 12 reverse
Two-speed power shift with left-hand synchronized shuttle.
JX90U two-speed power shift speeds

Transmission — 24 forward and reverse power shuttle

Type
power shuttle
Gears
24 forward and reverse
Four gears (1-4) in three ranges (I, II, III) with push-button power shift and power shuttle

Transmission — 20 forward and 12 reverse syncromesh

Type
syncromesh
Gears
20 forward and 12 reverse

Dimensions

CaseIH JX90U Tires
Dimensions
2WD Wheelbase
92.2 inches 234 cm
4WD Wheelbase
91.1 inches 231 cm
CaseIH JX90U Weight
2WD Operating
8,070 lbs 3660 kg
4WD Operating
8,710 lbs 3950 kg
2WD Ballasted
9,885 lbs 4483 kg
4WD Ballasted
10,525 lbs 4774 kg
CaseIH JX90U Height
ROPS
108.75 inches 276 cm
Cab
103.25 inches 262 cm
Exhaust
109.5 inches 278 cm

Tests

OCED Tractor Test 2078
Diesel 24-speed 4WD October 1, 2002 - December 1, 2003 Link: OCED Tractor Test 2078 file
PTO performance
Power at rated engine speed
78.0 hp 58.2 kW
Fuel use
4.8 gal/hour 18.2 l/hour
Power at rated PTO speed
80.9 hp 60.3 kW
Fuel use
4.6 gal/hour 17.4 l/hour
Drawbar performance
Max power
65.4 hp 48.8 kW
Gear 12 used for power test.

Attachments

Attachment overview
CaseIH LX132 loader
CaseIH LX152 loader

Photos

CaseIH JX90U tractor photo

CaseIH JX90U tractor photo

Recommended Implements & Sizing Guide

Engineering recommendations for Caseih JX90U based on its 84 HP power envelope and ASAE agricultural standards.

Implement & OperationRecommended SizeWorkload RatingEngineering Notes
Moldboard PlowPrimary Tillage
3 to 4 Bottom (16")3 - 4 铧 (40 cm)Heavy DutySuitable for medium loam and stubble turnover.
Rotary Cutter / MowerMowing & Clearing
7 to 8 ft (84-96 in)2.1 - 2.4 mHeavy DutyHeavy-duty twin spindle cutter for overgrown acreage.
Rotary TillerSeedbed Prep
78 to 84 in200 - 215 cmHeavy DutyHeavy commercial tiller with multi-speed gearbox.
Disc HarrowSecondary Tillage
10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙Heavy DutyAggressive residue cutting in corn/cotton stubble.
Hay BalerHay & Forage
4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机Heavy DutySilage and dry hay; 540 RPM PTO with slip-clutch.
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Caseih JX90U.

Estimated Continuous Field Runtime: 7.7 hrs

Approximately 7.7 hours of continuous field operation at ~75% rated power on a full tank (33.5 gal / 126.8 L).

Estimated 75% Load Fuel Burn~4.4 gal/hr (16.5 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours

Caseih JX90U Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Caseih JX90U.

Converted Equivalents:

Horsepower (HP)84 hp
Kilowatts (kW)62.6 kW
Metric Horsepower (PS / CV)85.2 PS
