CaseIH MX80C

The CaseIH MX80C is a tractor produced by Caseih. It is equipped with a 243.5 ci 4.0 L engine. The rated power output is 84 hp 62.6 kW. Transmission: 32 forward and 24 reverse. Operating weight: 9921 to 10580 pounds.

Overview

	1998 - 2002 Utility tractor
1998 - 2002
Utility tractor

Production
Manufacturer	CaseIH
Utility tractor
Built in Doncaster, England
Original price	$53,000 (1999)

CaseIH MX80C Engine
Perkins 4.0L 4-cyl diesel
Engine details ...

CaseIH MX80C Power
Engine	84 hp 62.6 kW
PTO (claimed)	67 hp 50.0 kW
Drawbar (tested)	57.3 hp 42.7 kW
PTO (tested)	67.8 hp 50.6 kW
Performance test details ...

Mechanical
Four-wheel drive
Steering	hydrostatic power
Differential hydraulic wet disc brakes
Cab standard.

Capacity
Fuel	50 gal 189.2 L
Hydraulic system	17.5 gal 66.2 L

Hydraulics
Type	closed center pressure-flow compensating (PFC)
Capacity	17.5 gal 66.2 L
Pressure	2950 psi 203.4 bar
Valves	2 to 4
Pump flow	25 gpm 94.6 lpm
Total flow	28.9 gpm 109.4 lpm

Tractor hitch
Rear Type	II
Control	electronic lower link
Rear lift (at 24"/610mm)	8,393 lbs 3807 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electrically-actuated wet disc
Rear PTO Type	540/1000 (1.375)
Engine RPM	540@1875
	1000@2210

Dimensions & Tires
Wheelbase	95.4 inches 242 cm
Weight	9921 to 10580 pounds
Front tire	12.4R-24
Rear tire	16.9-34
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	95
Charging volts	12
Batteries	2
Battery CCA	700
Battery volts	12

References
MX Series Tractors published in 1998, by CaseIH

Engine

Engine Detail — 243.5 ci / 4.0 L Diesel

Manufacturer	Perkins
Configuration	turbocharged diesel, 4-cylinder, liquid-cooled
Displacement	243.5 ci 4.0 L
Bore/Stroke	3.937x5.00 inches 100 x 127 mm
Power	84 hp 62.6 kW
Fuel system	direct-injection with mechanical governor, rotary injection pump with 5-hole nozzles
Air cleaner	dual paper elements
Compression	17.25:1
Rated RPM	2200
Starter volts	12
Oil capacity	9.3 qts 8.8 L
Coolant capacity	16.6 qts 15.7 L

CaseIH MX80C Engine

Transmission

Transmission options
16-speed partial power shift
32-speed creeper

Transmission — 16 forward and 12 reverse partial power shift

Type	partial power shift
Gears	16 forward and 12 reverse
Clutch	hydraulic wet discs
Four power shift speeds (1-4) in four synchronized ranges (I-IV) with power shuttle. Three ranges in reverse.
Transmission
Type	creeper
Gears	32 forward and 24 reverse

Dimensions

CaseIH MX80C Tires
Ag front	12.4R-24
Ag rear	16.9-34

Dimensions
Wheelbase	95.4 inches 242 cm
Length	170.6 inches 433 cm
Height (cab)	110.3 inches 280 cm
Shipping weight	9,921 lbs 4500 kg
Operating weight	10,580 lbs 4799 kg

Tests

OCED Tractor Test 1930
Diesel 16-speed 4WD March 1 - 31, 2000 Link: OCED Tractor Test 1930 file
PTO performance
Max power	67.8 hp 50.6 kW
Fuel use	4.5 gal/hour 17.0 l/hour
Power at rated engine speed	67.1 hp 50.0 kW
Fuel use	4.7 gal/hour 17.8 l/hour
Drawbar performance
Max power	57.3 hp 42.7 kW
Fuel use	4.8 gal/hour 18.2 l/hour
Gear 2-II used for power test.
Max pull	11,080 lbs 5025 kg
Gear 2-I used for pull test.

Photos

CaseIH MX80C tractor photo
