CaseIH Steiger 525

The CaseIH Steiger 525 is a tractor produced by Caseih. It is equipped with a 787 ci 12.9 L engine. The rated power output is 517.8 hp 386.1 kW. Transmission: CVXDrive. Operating weight: 40800 lbs 18506 kg.

Overview

	2024 - Steiger 4WD SeriesFour-wheel Drive (4WD) tractor
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor

Production
Manufacturer	CaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA

CaseIH Steiger 525 Engine
FPT 12.9L 6-cyl diesel
Fuel tank	310 gal 1173.4 L
Exhaust fluid (DEF)	42 gal 159.0 L
Engine details ...

CaseIH Steiger 525 Power
Engine (gross)	517.8 hp 386.1 kW
Engine (max)	570.1 hp 425.1 kW
PTO (claimed)	508.9 hp 379.5 kW

Mechanical
Four-wheel drive
Final drives	planetary
Differential lock	automatic front and rear
Articulated power steering
Cab standard with air-conditioning.

Hydraulics
Type	closed center
Valves	4 to 8
Pump flow	42 gpm 159.0 lpm
	57 gpmOptOptional 215.7 lpm
	113 gpmOptOptional 427.7 lpm
SCV flow	35 gpm 132.5 lpm

Tractor hitch
Rear Type	IVN/III
Rear lift (at 24"/610mm)	21903 lbs 9935 kg
Drawbar	Cat 4
	Cat 5 OptOptional

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	1000 (1.75)

Dimensions & Tires
Wheelbase	148 inches 375 cm
Weight	40800 lbs 18506 kg
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	240
	330 OptOptional
Batteries	3
Battery CCA	950
Battery volts	12

References
TAFS Connect Steiger published in 2024, by New Holland

Engine

Engine Detail — 787 ci / 12.9 L Diesel

Manufacturer	FPT Cursor 13
Configuration	turbocharged diesel, 6-cylinder 24-valve, liquid-cooled
Displacement	787 ci 12.9 L
Bore/Stroke	5.31x5.91 inches 135 x 150 mm
Emissions	Tier IV
Rated Power (gross)	517.8 hp 386.1 kW
Maximum Power (gross)	570.1 hp 425.1 kW
Rated RPM	2100
Starter	electric
Starter volts	12

CaseIH Steiger 525 Engine

Transmission

Transmission options
17-speed full power shift
continuously-variable transmission

Transmission — PowerDrive

Transmission	PowerDrive
Type	full power shift
Gears	17 forward and 2 reverse

CaseIH Steiger 525 Transmission

Transmission — CVXDrive

Transmission	CVXDrive
Type	continuously-variable transmission
Gears	infinite forward and reverse

CaseIH Steiger 525 Transmission

Dimensions

CaseIH Steiger 525 Tires

Dimensions
Wheelbase	148 inches 375 cm
Front axle	Bar: 5 by 120 inches 127 by 3048 mm
Bar rear axle	5 by 120 inches 127 by 3048 mm

CaseIH Steiger 525 Weight
Shipping	40800 lbs 18506 kg
Max capacity	56000 lbs 25401 kg
Max Drawbar	6000 lbs (Cat 4) 2721 kg
	11000 lbs (Cat 4)OptOptional 4989 kg
	15000 lbs (Cat 5) 6804 kg
