New Holland T9.520

The New Holland T9.520 is a tractor produced by New Holland. It is equipped with a 787 ci 12.9 L engine. The rated power output is 468.5 hp 349.4 kW. Transmission: Auto Command. Operating weight: 40800 lbs 18506 kg.

Overview

	2024 - T9 SeriesFour-wheel Drive (4WD) tractor
2024 -
T9 Series
Four-wheel Drive (4WD) tractor

2024 -
T9 Series
Four-wheel Drive (4WD) tractor

Production
Manufacturer	New Holland (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA

New Holland T9.520 Engine
FPT 12.9L 6-cyl diesel
Fuel tank	310 gal 1173.4 L
Exhaust fluid (DEF)	42 gal 159.0 L
Engine details ...

New Holland T9.520 Transmissions
17-speed full power shift
continuously-variable transmission
Transmission details ...

New Holland T9.520 Power
Engine (gross)	468.5 hp 349.4 kW
Engine (max)	514.9 hp 384.0 kW
PTO (claimed)	455.7 hp 339.8 kW

Mechanical
Four-wheel drive
Final drives	planetary
Differential lock	automatic front and rear
Articulated power steering
Brakes	hydraulic wet disc
	engine brake
Cab standard with air-conditioning.

Hydraulics
Type	closed center
Pump flow	42 gpm 159.0 lpm
	57 gpmOptOptional 215.7 lpm
	98 gpmOptOptional 370.9 lpm
	113 gpmOptOptional 427.7 lpm

Tractor hitch
Rear Type	IVN/III
Rear lift (at 24"/610mm)	21903 lbs 9935 kg
Drawbar	Cat 4
	Cat 5 OptOptional

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	1000 (1.75)
Engine RPM	1000@1811

Dimensions & Tires
Wheelbase	148 inches 375 cm
Weight	40800 lbs 18506 kg
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	240
	330 OptOptional
Batteries	3
Battery CCA	950
Battery volts	12

References
T9 Series with PLM Intelligence published in 2024, by New Holland*
*Publication contains known errors.

Engine

	2024 - T9 SeriesFour-wheel Drive (4WD) tractor
2024 -
T9 Series
Four-wheel Drive (4WD) tractor

2024 -
T9 Series
Four-wheel Drive (4WD) tractor

Engine Detail
FPT Cursor 13
turbocharged aftercooled diesel
6-cylinder 24-valve
liquid-cooled
Displacement	787 ci 12.9 L
Bore/Stroke	5.31x5.91 inches 135 x 150 mm
Emissions	Tier IV
Rated Power (gross)	468.5 hp 349.4 kW
Maximum Power (gross)	514.9 hp 384.0 kW
Rated RPM	2100
Starter	electric
Starter volts	12

New Holland T9.520 Engine

Transmission

	2024 - T9 SeriesFour-wheel Drive (4WD) tractor
2024 -
T9 Series
Four-wheel Drive (4WD) tractor

2024 -
T9 Series
Four-wheel Drive (4WD) tractor

Transmission options
17-speed full power shift
continuously-variable transmission

Transmission
Transmission	Ultra Command
Type	full power shift
Gears	17 forward and 2 reverse

Speeds

New Holland T9.520 Transmission

Transmission
Transmission	Auto Command
Type	continuously-variable transmission
Gears	infinite forward and reverse

New Holland T9.520 Transmission

Dimensions

	2024 - T9 SeriesFour-wheel Drive (4WD) tractor
2024 -
T9 Series
Four-wheel Drive (4WD) tractor

2024 -
T9 Series
Four-wheel Drive (4WD) tractor

New Holland T9.520 Tires

Dimensions
Wheelbase	148 inches 375 cm
Front axle	Bar: 5.0 by 120 inches 127 by 3048 mm
Bar rear axle	5.0 by 120 inches 127 by 3048 mm

New Holland T9.520 Weight
Shipping	40800 lbs 18506 kg
Max capacity	56000 lbs 25401 kg
Max Drawbar	6000 lbs (Cat 4) 2721 kg
	11000 lbs (Cat 4)OptOptional 4989 kg
	15000 lbs (Cat 5) 6804 kg
