Craftsman 917.28858
The Craftsman 917.28858 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 724 cc 44.18 ci engine. The rated power output is 26 hp 19.4 kW. Transmission: Tuff Torq K46. Operating weight: 556 lbs 252 kg.
Engine Power
26 hp
19.4 kW
Fuel & Capacities
3 gal
11.4 L
Transmission
Tuff Torq K46
Operating Weight
556 lbs
252 kg
Craftsman Lawn Tractors Craftsman 917.28858 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2011 - 2013
YT 4500 SeriesLawn tractorHusqvarna built |
|---|---|
2011 - 2013 | |
YT 4500 Series | |
Lawn tractor | |
Husqvarna built | |
2011 - 2013 | |
|---|---|
YT 4500 Series | |
Lawn tractor | |
Husqvarna built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Husqvarna |
Lawn tractor | |
Original price | $2,048 (2012) |
Variants | |
|---|---|
917.28863 | California emissions |
Craftsman 917.28858 Engine | |
|---|---|
26HP Briggs & Stratton 724cc 2-cyl gasoline | |
Fuel tank | 3 gal
11.4 L |
Engine details ...  | |
Craftsman 917.28858 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual sector and pinion |
Mechanical disc brakes | |
Open operator station. High-back seat with sliding adjustment. | |
Dimensions & Tires | |
|---|---|
Weight | 556 lbs
252 kg |
Front tire | 15x6x6 |
Rear tire | 20x10x8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 16 |
Battery CCA | 230 |
Battery volts | 12 |
Battery AH | 28 |
Battery Group | U1R |
References | |
|---|---|
 | |
2011 Customer Buying Guide published by Sears | |
2012 Customer Buying Guide published by Sears |
Engine
| 2011 - 2013
YT 4500 SeriesLawn tractorHusqvarna built |
|---|---|
2011 - 2013 | |
YT 4500 Series | |
Lawn tractor | |
Husqvarna built | |
2011 - 2013 | |
|---|---|
YT 4500 Series | |
Lawn tractor | |
Husqvarna built |
Engine Detail — 724 cc / 44.18 ci Gasoline
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled |
Briggs & Stratton Platinum 445877 | |
Displacement | 724 cc
44.18 ci |
Power (gross) | 26 hp
19.4 kW |
Air cleaner | paper |
Rated RPM | 3600 |
Starter | electric |
Starter volts | 12 |
Sparkplug | Champion QC12YC |
Sparkplug gap | 0.040 inches
1.016 mm |
Intake valve clearance | 0.005 inches
0.127 mm |
Exhaust valve clearance | 0.005 inches
0.127 mm |
Oil capacity | 2 qts
1.9 L |
Transmission
| 2011 - 2013
YT 4500 SeriesLawn tractorHusqvarna built |
|---|---|
2011 - 2013 | |
YT 4500 Series | |
Lawn tractor | |
Husqvarna built | |
2011 - 2013 | |
|---|---|
YT 4500 Series | |
Lawn tractor | |
Husqvarna built |
Transmission — Tuff Torq K46
Transmission | Tuff Torq K46 |
Type | hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
| 2011 - 2013
YT 4500 SeriesLawn tractorHusqvarna built |
|---|---|
2011 - 2013 | |
YT 4500 Series | |
Lawn tractor | |
Husqvarna built | |
2011 - 2013 | |
|---|---|
YT 4500 Series | |
Lawn tractor | |
Husqvarna built |
Craftsman 917.28858 Tires | |
|---|---|
Lawn/turf front | 15x6x6 |
Lawn/turf rear | 20x10x8 |
Dimensions | |
|---|---|
Weight | 556 lbs
252 kg |
Attachments
| 2011 - 2013
YT 4500 SeriesLawn tractorHusqvarna built |
|---|---|
2011 - 2013 | |
YT 4500 Series | |
Lawn tractor | |
Husqvarna built | |
2011 - 2013 | |
|---|---|
YT 4500 Series | |
Lawn tractor | |
Husqvarna built |
54" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
3-blade with manual lift | |
Cutting width | 54 inches
137 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | 6 |
Photos
Craftsman 917.28858
Craftsman 917.28858
Craftsman 28858 operator station and controls.
Craftsman Lawn Tractors Craftsman 917.28858 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 917.28858.
Converted Equivalents:
Horsepower (HP)26 hp
Kilowatts (kW)19.4 kW
Metric Horsepower (PS / CV)26.4 PS
