Craftsman 917.28925
The Craftsman 917.28925 is a tractor produced by Craftsman Lawn Tractors. It is equipped with a 724 cc 44.18 ci engine. The rated power output is 24 hp 17.9 kW. Transmission: 6 forward and 1 reverse. Operating weight: 506 lbs 229 kg.
Engine Power
24 hp
17.9 kW
Fuel & Capacities
3 gal
11.4 L
Transmission
6 forward and 1 reverse
Operating Weight
506 lbs
229 kg
Craftsman Lawn Tractors Craftsman 917.28925 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2009 - 2011
YT 4000 SeriesLawn tractorHusqvarna built |
|---|---|
2009 - 2011 | |
YT 4000 Series | |
Lawn tractor | |
Husqvarna built | |
2009 - 2011 | |
|---|---|
YT 4000 Series | |
Lawn tractor | |
Husqvarna built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | Husqvarna |
Lawn tractor | |
Original price | $1,865 (2010) |
Craftsman 917.28925 Engine | |
|---|---|
24HP Briggs & Stratton 724cc 2-cyl gasoline | |
Fuel tank | 3 gal
11.4 L |
Engine details ...  | |
Craftsman 917.28925 Transmission | |
|---|---|
6-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | manual sector and pinion |
Disc brakes | |
Open operator station with adjustable seat and cup holder. | |
Dimensions & Tires | |
|---|---|
Weight | 506 lbs
229 kg |
Front tire | 15x6x6 |
Rear tire | 18x9.5x8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 3 (battery) |
5 (headlights) | |
Battery CCA | 230 |
Battery volts | 12 |
Battery AH | 28 |
Battery Group | U1R |
References | |
|---|---|
 | |
2009 Riding Equipment published by Sears | |
2011 Customer Buying Guide published by Sears |
Engine
| 2009 - 2011
YT 4000 SeriesLawn tractorHusqvarna built |
|---|---|
2009 - 2011 | |
YT 4000 Series | |
Lawn tractor | |
Husqvarna built | |
2009 - 2011 | |
|---|---|
YT 4000 Series | |
Lawn tractor | |
Husqvarna built |
Engine Detail — 724 cc / 44.18 ci Gasoline
Manufacturer | Briggs & Stratton |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled |
Displacement | 724 cc
44.18 ci |
Power (gross) | 24 hp
17.9 kW |
Air cleaner | paper element |
Starter | electric |
Starter volts | 12 |
Oil capacity | 2 qts
1.9 L |
Sparkplug | Champion QC12YC |
Sparkplug gap | 0.040 inches
1.016 mm |
Transmission
| 2009 - 2011
YT 4000 SeriesLawn tractorHusqvarna built |
|---|---|
2009 - 2011 | |
YT 4000 Series | |
Lawn tractor | |
Husqvarna built | |
2009 - 2011 | |
|---|---|
YT 4000 Series | |
Lawn tractor | |
Husqvarna built |
Transmission — 6 forward and 1 reverse gear
Type | gear |
Gears | 6 forward and 1 reverse |
 | |
Dimensions
| 2009 - 2011
YT 4000 SeriesLawn tractorHusqvarna built |
|---|---|
2009 - 2011 | |
YT 4000 Series | |
Lawn tractor | |
Husqvarna built | |
2009 - 2011 | |
|---|---|
YT 4000 Series | |
Lawn tractor | |
Husqvarna built |
Craftsman 917.28925 Tires | |
|---|---|
Lawn/turf front | 15x6x6 |
Lawn/turf rear | 18x9.5x8 |
Dimensions | |
|---|---|
Weight | 506 lbs
229 kg |
Attachments
| 2009 - 2011
YT 4000 SeriesLawn tractorHusqvarna built |
|---|---|
2009 - 2011 | |
YT 4000 Series | |
Lawn tractor | |
Husqvarna built | |
2009 - 2011 | |
|---|---|
YT 4000 Series | |
Lawn tractor | |
Husqvarna built |
Attachment overview | |
|---|---|
Optional two (24891) or three (24892) bin bagger. |
42" Mower deck | |
|---|---|
Type | mid-mount Craftsman |
2-blade with manual lift | |
Cutting width | 42 inches
106 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Cut positions | 6 |
Photos
Craftsman 917.28925 tractor photo
Craftsman Lawn Tractors Craftsman 917.28925 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Craftsman Lawn Tractors Craftsman 917.28925.
Converted Equivalents:
Horsepower (HP)24 hp
Kilowatts (kW)17.9 kW
Metric Horsepower (PS / CV)24.3 PS
