Cub Cadet 7252
The Cub Cadet 7252 is a tractor produced by Cub Cadet. It is equipped with a 45.6 ci 0.7 L engine. The rated power output is 25 hp 18.6 kW. Transmission: infinite forward and reverse (2-range). Operating weight: 950 lbs 430 kg.
Engine Power
25 hp
18.6 kW
Fuel & Capacities
6 gal
22.7 L
Transmission
infinite forward and reverse (2-range)
Operating Weight
950 lbs
430 kg
Cub Cadet 7252 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2003
7000 SeriesCompact Utility tractor |
|---|---|
2003 | |
7000 Series | |
Compact Utility tractor | |
Production | |
|---|---|
Manufacturer | Cub Cadet |
Compact Utility tractor | |
Original price was $10,000 in 2003 | |
Variants | |
|---|---|
7252 | 2WD |
7254 | 4WD |
Cub Cadet 7252 Engine | |
|---|---|
Kawasaki 0.7L 2-cyl gasoline | |
Engine details ...  |
Cub Cadet 7252 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Cub Cadet 7252 Power | |
|---|---|
Engine | 25 hp
18.6 kW |
PTO (claimed) | 20 hp
14.9 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Differential lock | mechanical rear |
Steering | hydrostatic power |
Dry shoe brakes | |
Two-post foldable ROPS. | |
Capacity | |
|---|---|
Fuel | 6 gal
22.7 L |
Hydraulic system | 6 gal
22.7 L |
Hydraulics | |
|---|---|
Type | open center gear pump |
Capacity | 6 gal
22.7 L |
Pressure | 1500 psi
103.4 bar |
Pump flow | 5 gpm
18.9 lpm |
Total flow | 8 gpm
30.3 lpm |
Steering flow | 3 gpm
11.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Rear lift (at ends) | 1150 lbs
521 kg |
Rear lift (at 24"/610mm) | 950 lbs
430 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electric |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@3500 |
Mid PTO | independent |
Clutch | electric |
Mid PTO Type | 2000 (1.000) |
Dimensions & Tires | |
|---|---|
Wheelbase | 58 inches
147 cm |
Weight | 1597 lbs
724 kg |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | flywheel alternator |
Charging amps | 30 |
Battery CCA | 500 |
Battery volts | 12 |
References | |
|---|---|
 | |
Outdoor Power Equipment 2003 published by Cub Cadet | |
Operator's Manual Series Front-end Loader model 610 (770-10585) published in 2002 | |
Operator's Manual 612 Backhoe (769-00150A) published in 2005 |
Engine
Engine Detail — 45.6 ci / 0.7 L Gasoline
Manufacturer | Kawasaki FD750 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, liquid-cooled |
Displacement | 45.6 ci
0.7 L |
Bore/Stroke | 3.07x3.07 inches
78 x 78 mm |
Power | 25 hp
18.6 kW |
Fuel system | dual carburetor |
Air cleaner | paper element |
Pre-heating | coolant heater (optional) |
Rated RPM | 3600 |
Idle RPM | 1550-3600 |
Starter | electric |
Starter volts | 12 |
Coolant capacity | 3.5 qts
3.3 L |
Coolant change | 400 h |
Sparkplug gap | 0.030 inches
0.762 mm |
Intake valve clearance | 0.006 inches (cold)
0.152 mm |
Exhaust valve clearance | 0.006 inches (cold)
0.152 mm |
Oil capacity | 2.1 qts
2.0 L |
Oil change | 100 h |
Transmission
Transmission — infinite forward and reverse (2-range) hydrostatic
Type | hydrostatic |
Gears | infinite forward and reverse (2-range) |
Oil capacity | 24 qts
22.7 L |
Oil type | Cab Cadet Hy-Trans Fluid |
Hydrostatic transmission with forward-reverse tredle pedal and high-low range shift. Tractor must be stopped to shift range. | |
 | |
Cab Cadet Hy-Trans Fluid |
|---|
Dimensions
Cub Cadet 7252 Tires | |
|---|---|
Lawn/turf front | 20x9-8 |
Lawn/turf rear | 27x12-15 |
Dimensions | |
|---|---|
Wheelbase | 58 inches
147 cm |
Length | 91 inches
231 cm |
109 inches (with hitch)
276 cm | |
Width | 48 inches
121 cm |
Height | 53 inches
134 cm |
Height (ROPS) | 79 inches
200 cm |
Weight | 1597 lbs
724 kg |
Ground clearance | 8 inches
20 cm |
Attachments
Attachment overview | |
|---|---|
54" mid-mount mower deck | |
60" mid-mount mower deck | |
Snowblower | |
Blade | |
Front-end loader | |
Backhoe | |
In addition to the mid-mount mowers, the Cub Cadet 7252 was advertised as compatible with 60-inch rear-mount finish mower and 48-inch rotary cutter. Recommended ground tools included a 48-inch box blade, 60-inch rear blade, and 50-inch tiller. |
Cub Cadet 612 Backhoe | |
|---|---|
Backhoe type | Cub Cadet 612 Backhoe |
Weight | 950 lbs
430 kg |
Digging depth | 78 inches
198 cm |
Reach from pivot | 94 inches
238 cm |
Loading height | 52.5 inches
133 cm |
Bucket Rotation | 180° |
Swing Arc | 180° |
Bucket force | 1935 lbs
877 kg |
Dipperstick force | 1010 lbs
458 kg |
Photos
Cub Cadet 7252 tractor photo
Cub Cadet 7252 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Cub Cadet 7252.
Converted Equivalents:
Horsepower (HP)25 hp
Kilowatts (kW)18.6 kW
Metric Horsepower (PS / CV)25.3 PS
