Cub Cadet GT 1222

The Cub Cadet GT 1222 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 655 cc 40 ci engine. The rated power output is 22 hp 16.4 kW. Transmission: Hydro-Gear 311-3000. Operating weight: 150 lbs 68 kg.

Overview

	2004 Lawn tractor
2004
Lawn tractor

Production
Manufacturer	Cub Cadet (a part of MTD)
Lawn tractor

Cub Cadet GT 1222 Engine
22HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank	3 gal 11.4 L
Engine details ...

Cub Cadet GT 1222 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Dry disc brakes
Open operator station.

Power Take-off (PTO)
Front PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	48 inches 121 cm
Weight	529 lbs 239 kg
Front tire	16x6.5
Rear tire	23x9.5
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	16
Battery CCA	270
Battery volts	12

References
Outdoor Power Equipment published in 2004, by Cub Cadet

Engine

Engine Detail — 655 cc / 40 ci Gasoline

Manufacturer	Briggs & Stratton 40H777
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled
Displacement	655 cc 40 ci
Bore/Stroke	2.97x2.89 inches 75 x 73 mm
Power (gross)	22 hp 16.4 kW
Compression	8.5:1
Rated RPM	3600
Idle RPM	1200-3300
Torque	32.7 lb-ft 44.3 Nm
Torque RPM	2400
Starter	electric
Starter volts	12
Oil capacity	2 qts 1.9 L
Sparkplug gap	0.030 inches 0.762 mm

Transmission

Transmission — Hydro-Gear 311-3000

Transmission	Hydro-Gear 311-3000
Type	belt-driven hydrostatic
Gears	infinite forward and reverse

Dimensions

Cub Cadet GT 1222 Tires
Lawn/turf front	16x6.5
Lawn/turf rear	23x9.5

Dimensions
Wheelbase	48 inches 121 cm
Length	68.5 inches 173 cm
Width	42 inches 106 cm
Weight	529 lbs 239 kg
Ground clearance	6 inches 15 cm

Attachments

Attachment overview
46" mid-mount mower deck
Snowblower
Blade

46" Mower deck
Type	mid-mount Cub Cadet
	manual lift
Cutting width	46 inches 116 cm
Weight	150 lbs 68 kg
Cut height	1.5 to 4 inch 3 to 10 cm

Photos

Cub Cadet GT 1222 tractor photo
