Cub Cadet GT 2523
The Cub Cadet GT 2523 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 673 cc 41.1 ci engine. The rated power output is 23 hp 17.2 kW. Transmission: infinite forward and reverse. Operating weight: 191 lbs 86 kg.
Engine Power
23 hp
17.2 kW
Fuel & Capacities
2.25 gal
8.5 L
Transmission
infinite forward and reverse
Operating Weight
191 lbs
86 kg
Cub Cadet Lawn Tractors Cub Cadet GT 2523 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2004
2500 SeriesGarden tractor |
|---|---|
2004 | |
2500 Series | |
Garden tractor | |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Garden tractor | |
Cub Cadet GT 2523 Engine | |
|---|---|
23HP Kohler 673cc 2-cyl gasoline | |
Fuel tank | 2.25 gal
8.5 L |
Engine details ...  | |
Cub Cadet GT 2523 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Front PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 47 inches
119 cm |
Weight | 544 lbs
246 kg |
Front tire | 16x6.5 |
Rear tire | 23x9.5 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 15 |
Battery CCA | 275 |
Battery volts | 12 |
References | |
|---|---|
 | |
Outdoor Power Equipment published in 2004, by Cub Cadet |
Engine
Engine Detail — 673 cc / 41.1 ci Gasoline
Manufacturer | Kohler CH23S |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled |
Displacement | 673 cc
41.1 ci |
Bore/Stroke | 3.15x2.64 inches
80 x 67 mm |
Power (gross) | 23 hp
17.2 kW |
Rated RPM | 3350 |
Idle RPM | 1400-3600 |
Torque | 37.9 lb-ft
51.4 Nm |
Torque RPM | 2400 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 2 qts
1.9 L |
Transmission
Transmission — infinite forward and reverse shaft-driven hydrostatic
Type | shaft-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 7 qts
6.6 L |
 | |
Dimensions
Cub Cadet GT 2523 Tires | |
|---|---|
Lawn/turf front | 16x6.5 |
Lawn/turf rear | 23x9.5 |
Dimensions | |
|---|---|
Wheelbase | 47 inches
119 cm |
Length | 72 inches
182 cm |
Width | 39 inches
99 cm |
Height (steering wheel) | 42 inches
106 cm |
Weight | 544 lbs
246 kg |
Ground clearance | 6 inches
15 cm |
4-bolt rear axle | 1 inch diameter
25 mm |
Attachments
Attachment overview | |
|---|---|
54" mid-mount mower deck | |
Snowblower | |
Blade | |
Garden tractors are capable of using tillers, plows, or other ground-engaging attachments. TractorData does not list details of these attachments. |
54" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
Cutting width | 54 inches
137 cm |
Weight | 191 lbs
86 kg |
Cut height | 2 to 4 inch
5 to 10 cm |
Photos
Cub Cadet GT 2523 tractor photo
