Cub Cadet LT 2180

The Cub Cadet LT 2180 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 568 cc 34.7 ci engine. The rated power output is 18 hp 13.4 kW. Transmission: infinite forward and reverse.

Overview

	2004 Lawn tractor
2004
Lawn tractor

Production
Manufacturer	Cub Cadet (a part of MTD)
Lawn tractor

Cub Cadet LT 2180 Engine
18HP Briggs & Stratton 568cc 2-cyl gasoline
Fuel tank	2.1 gal 7.9 L
Engine details ...

Cub Cadet LT 2180 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Steering	manual
Internal expanding brakes
Open operator station.

Power Take-off (PTO)
Front PTO	independent
Clutch	electric

Dimensions & Tires
Wheelbase	47 inches 119 cm
Front tire	15x6-6
Rear tire	20x9-8
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	15
Battery volts	12

References
Outdoor Power Equipment published in 2004, by Cub Cadet

Engine

Engine Detail — 568 cc / 34.7 ci Gasoline

Manufacturer	Briggs & Stratton Vanguard
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled
Displacement	568 cc 34.7 ci
Bore/Stroke	2.83x2.76 inches 72 x 70 mm
Power (gross)	18 hp 13.4 kW
Rated RPM	3600
Idle RPM	1200-3600
Starter	electric
Starter volts	12
Sparkplug gap	0.030 inches 0.762 mm
Oil capacity	1.5 qts 1.4 L
Oil change	50 h

Transmission

Transmission — infinite forward and reverse shaft-driven hydrostatic

Type	shaft-driven hydrostatic
Gears	infinite forward and reverse
Oil capacity	6 qts 5.7 L

Dimensions

Cub Cadet LT 2180 Tires
Lawn/turf front	15x6-6
Lawn/turf rear	20x9-8

Dimensions
Wheelbase	47 inches 119 cm
Length	72 inches 182 cm
Width	51 inches 129 cm
Height (steering wheel)	42 inches 106 cm
Ground clearance	6 inches 15 cm

Attachments

42" Mower deck
Type	mid-mount Cub Cadet
	2-blade with manual lift
Cutting width	42 inches 106 cm

Photos

Cub Cadet LT 2180 tractor photo
