Cub Cadet LTX 1042 KW

The Cub Cadet LTX 1042 KW is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 603 cc 36.8 ci engine. The listed engine power is Gasoline (gross): 18 hp / 13.4 kW. Transmission: Tuff Torq. Operating weight: 498 lbs 225 kg.

Engine Power

Gasoline (gross): 18 hp / 13.4 kW

Fuel & Capacities

3.3 gal 12.5 L

Transmission

Tuff Torq

Operating Weight

498 lbs 225 kg

Overview

	2012 - 2014 LTX 1000 SeriesLawn tractor LTX 1000 Series Lawn tractor

Production
Manufacturer	Cub Cadet (a part of MTD)
Lawn tractor

Cub Cadet LTX 1042 Engine
18HP Kawasaki 603cc 2-cyl gasoline
Fuel tank	3.3 gal 12.5 L
Engine details ...

Cub Cadet LTX 1042 Transmission
hydrostatic
Transmission details ...

Mechanical
Two-wheel drive
Manual steering
Open operator station.

Power Take-off (PTO)
Front PTO	independent
Clutch	manual lever

Dimensions & Tires
Wheelbase	47.5 inches 120 cm
Weight	498 lbs 225 kg
Front tire	15x6
Rear tire	20x8
Full dimensions and tires ...

Electrical
Ground	negative
Charging amps	15
Battery CCA	230
Battery volts	12

References

Series 1000 published in 2012, by Cub Cadet
Series 1000 published in 2013, by Cub Cadet
Series 1000 published in 2014, by Cub Cadet

Engine

Engine Detail — 603 cc / 36.8 ci Gasoline

Manufacturer	Kawasaki FR600V
Fuel Type	Gasoline
Configuration	2-cylinder, air-cooled
Displacement	603 cc 36.8 ci
Bore/Stroke	2.87x2.84 inches 73 x 72 mm
Power (gross)	18 hp 13.4 kW
Rated RPM	3600
Starter	electric
Starter volts	12
Oil capacity	1.6 qts 1.5 L

Transmission

Transmission — Tuff Torq

Transmission	Tuff Torq
Type	belt-driven hydrostatic
Gears	infinite forward and reverse
Oil capacity	1.9 qts 1.8 L

Dimensions

Cub Cadet LTX 1042 Tires
Lawn/turf front	15x6
Lawn/turf rear	20x8

Dimensions
Wheelbase	47.5 inches 120 cm
Length	69 inches 175 cm
Weight	498 lbs 225 kg

Attachments

42" Mower deck
Type	mid-mount Cub Cadet
	2-blade
Cutting width	42 inches 106 cm
Cut height	1.5 to 4 inch 3 to 10 cm

Recommended Implements & Sizing Guide

Engineering recommendations for Cub Cadet Lawn Tractors Cub Cadet LTX 1042 KW based on its 18 HP power envelope and ASAE agricultural standards.

Implement & Operation	Recommended Size	Workload Rating	Engineering Notes
Moldboard PlowPrimary Tillage	1 to 2 Bottom (12")1 - 2 铧 (30 cm)	Light Duty	Ideal for garden plots and light sandy soil.
Rotary Cutter / MowerMowing & Clearing	4 ft (48 in)1.2 m	Light Duty	Pasture clipping and light brush under 1" diameter.
Rotary TillerSeedbed Prep	42 to 48 in105 - 120 cm	Light Duty	Covers compact tractor tire width.

Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.

Fluids, Capacities & Working Autonomy

Standard fluid requirements, service intervals, and continuous runtime estimates for Cub Cadet Lawn Tractors Cub Cadet LTX 1042 KW.

Estimated Continuous Field Runtime: 3.5 hrs

Approximately 3.5 hours of continuous field operation at ~75% rated power on a full tank (3.3 gal / 12.5 L).

Estimated 75% Load Fuel Burn~0.9 gal/hr (3.5 L/hr)

Engine Crankcase Oil

SAE 15W-40 (Heavy Duty Diesel)

Standard Spec: API CK-4 / CJ-4 Heavy Duty

Service Interval: 150 – 250 Hours

Transmission & Hydraulic System

UTTO (Universal Tractor Transmission Oil)

Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)

Service Interval: 600 – 1000 Hours

Engine Cooling System

50/50 Ethylene Glycol Pre-mix

Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze

Service Interval: 2 Years / 1500 Hours

Cub Cadet Lawn Tractors Cub Cadet LTX 1042 KW Specification Unit Converter

Convert power, fluid capacities, and operating weights between metric and imperial standards for Cub Cadet Lawn Tractors Cub Cadet LTX 1042 KW.

Enter value:

Unit:

Converted Equivalents:

Horsepower (HP)18 hp

Kilowatts (kW)13.4 kW

Metric Horsepower (PS / CV)18.2 PS
