Cub Cadet RZT 22
The Cub Cadet RZT 22 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 656 cc 40.03 ci engine. The rated power output is 22 hp 16.4 kW. Transmission: Hydro-Gear.
Engine Power
22 hp
16.4 kW
Fuel & Capacities
3 gal
11.4 L
Transmission
Hydro-Gear
Cub Cadet Lawn Tractors Cub Cadet RZT 22 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2004
RZT SeriesZero-turn mower |
|---|---|
2004 | |
RZT Series | |
Zero-turn mower | |
2004 | |
|---|---|
RZT Series | |
Zero-turn mower |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Zero-turn mower | |
Original price was $3,300 in 2004 | |
Cub Cadet RZT 22 Engine | |
|---|---|
22HP Briggs & Stratton 656cc 2-cyl gasoline | |
Fuel tank | 3 gal
11.4 L |
Engine details ...  | |
Cub Cadet RZT 22 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | differential power |
Power steering | |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Front tire | 11x4x5 |
Rear tire | 18x9.5x8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Outdoor Power Equipment published in 2004, by Cub Cadet | |
RZT Zero-Turn Riders published in 2004, by Cub Cadet |
Engine
| 2004
RZT SeriesZero-turn mower |
|---|---|
2004 | |
RZT Series | |
Zero-turn mower | |
2004 | |
|---|---|
RZT Series | |
Zero-turn mower |
Engine Detail — 656 cc / 40.03 ci Gasoline
Manufacturer | Briggs & Stratton 407577 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 656 cc
40.03 ci |
Bore/Stroke | 2.97x2.89 inches
75 x 73 mm |
Power (gross) | 22 hp
16.4 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 2004
RZT SeriesZero-turn mower |
|---|---|
2004 | |
RZT Series | |
Zero-turn mower | |
2004 | |
|---|---|
RZT Series | |
Zero-turn mower |
Transmission — Hydro-Gear
Transmission | Hydro-Gear |
Type | hydrostatic |
Gears | infinite forward and reverse |
Dimensions
| 2004
RZT SeriesZero-turn mower |
|---|---|
2004 | |
RZT Series | |
Zero-turn mower | |
2004 | |
|---|---|
RZT Series | |
Zero-turn mower |
Cub Cadet RZT 22 Tires | |
|---|---|
Lawn/turf front | 11x4x5 |
Lawn/turf rear | 18x9.5x8 |
Dimensions |
|---|
Attachments
| 2004
RZT SeriesZero-turn mower |
|---|---|
2004 | |
RZT Series | |
Zero-turn mower | |
2004 | |
|---|---|
RZT Series | |
Zero-turn mower |
50" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
3-blade | |
Cutting width | 50 inches
127 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Photos
Cub Cadet RZT 22 tractor photo
