Cub Cadet RZT 50 KH
The Cub Cadet RZT 50 KH is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 725 cc 44.24 ci engine. The rated power output is 23 hp 17.2 kW. Transmission: Hydro-Gear EZT. Operating weight: 527 lbs 239 kg.
Engine Power
23 hp
17.2 kW
Fuel & Capacities
2.8 gal
10.6 L
Transmission
Hydro-Gear EZT
Operating Weight
527 lbs
239 kg
Cub Cadet Lawn Tractors Cub Cadet RZT 50 KH Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2011 - 2012
RZT SeriesZero-turn mower |
|---|---|
2011 - 2012 | |
RZT Series | |
Zero-turn mower | |
2011 - 2012 | |
|---|---|
RZT Series | |
Zero-turn mower |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Zero-turn mower | |
Variants | |
|---|---|
50KH | Kohler engine |
50KW | Kawasaki engine |
Cub Cadet RZT 50 Engine | |
|---|---|
23HP Kohler 725cc 2-cyl gasoline | |
Fuel tank | 2.8 gal
10.6 L |
Engine details ...  | |
Cub Cadet RZT 50 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | differential power |
Power steering | |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 43.5 inches
110 cm |
Weight | 527 lbs
239 kg |
Front tire | 13x5.0-6 |
Rear tire | 18x9.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 15 |
Battery CCA | 230 |
Battery volts | 12 |
References | |
|---|---|
 | |
RZT Zero-Turn Mowers published in 2011, by Cub Cadet | |
RZT Series published in 2013, by Cub Cadet |
Engine
| 2011 - 2012
RZT SeriesZero-turn mower |
|---|---|
2011 - 2012 | |
RZT Series | |
Zero-turn mower | |
2011 - 2012 | |
|---|---|
RZT Series | |
Zero-turn mower |
Engine Detail — 725 cc / 44.24 ci Gasoline
Manufacturer | Kohler SV730 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 725 cc
44.24 ci |
Bore/Stroke | 3.27x2.64 inches
83 x 67 mm |
Power (gross) | 23 hp
17.2 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 2011 - 2012
RZT SeriesZero-turn mower |
|---|---|
2011 - 2012 | |
RZT Series | |
Zero-turn mower | |
2011 - 2012 | |
|---|---|
RZT Series | |
Zero-turn mower |
Transmission — Hydro-Gear EZT
Transmission | Hydro-Gear EZT |
Type | hydrostatic |
Gears | infinite forward and reverse |
 | |
Dimensions
| 2011 - 2012
RZT SeriesZero-turn mower |
|---|---|
2011 - 2012 | |
RZT Series | |
Zero-turn mower | |
2011 - 2012 | |
|---|---|
RZT Series | |
Zero-turn mower |
Cub Cadet RZT 50 Tires | |
|---|---|
Lawn/turf front | 13x5.0-6 |
Lawn/turf rear | 18x9.5-8 |
Dimensions | |
|---|---|
Wheelbase | 43.5 inches
110 cm |
Length | 80 inches
203 cm |
Height | 36 inches
91 cm |
Weight | 527 lbs
239 kg |
Attachments
| 2011 - 2012
RZT SeriesZero-turn mower |
|---|---|
2011 - 2012 | |
RZT Series | |
Zero-turn mower | |
2011 - 2012 | |
|---|---|
RZT Series | |
Zero-turn mower |
50" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
3-blade | |
Cutting width | 50 inches
127 cm |
Overall width | 57 inches
144 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Photos
Cub Cadet RZT 50 KH tractor photo
