Cub Cadet RZT L42
The Cub Cadet RZT L42 is a tractor produced by Cub Cadet Lawn Tractors. It is equipped with a 725 cc 44.24 ci engine. The rated power output is 22 hp 16.4 kW. Transmission: Hydro-Gear EZT-2200. Operating weight: 480 lbs 217 kg.
Engine Power
22 hp
16.4 kW
Fuel & Capacities
2.8 gal
10.6 L
Transmission
Hydro-Gear EZT-2200
Operating Weight
480 lbs
217 kg
Cub Cadet Lawn Tractors Cub Cadet RZT L42 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 2013 - 2024
Model year 2013-20142014-2024
RZT L SeriesZero-turn mower |
|---|---|
2013 - 2024 | |
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower | |
2013 - 2024 | |
|---|---|
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower |
Production | |
|---|---|
Manufacturer | Cub Cadet (a part of MTD) |
Zero-turn mower | |
Cub Cadet RZT L42 Engine | |
|---|---|
22HP Kohler 725cc 2-cyl gasoline | |
Fuel tank | 2.8 gal
10.6 L |
Engine details ...  | |
Cub Cadet RZT L42 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Steering | differential power |
Power steering | |
Open operator station. | |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Wheelbase | 43.5 inches
110 cm |
Weight | 480 lbs
217 kg |
Front tire | 11x4-5 |
Rear tire | 18x8.5-8 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 15 |
Battery CCA | 230 |
Battery volts | 12 |
References | |
|---|---|
 | |
RZT L Series published in 2014, by Cub Cadet |
Engine
| 2013 - 2024
Model year 2013-20142014-2024
RZT L SeriesZero-turn mower |
|---|---|
2013 - 2024 | |
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower | |
2013 - 2024 | |
|---|---|
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower |
Engine Detail — 725 cc / 44.24 ci Gasoline
Manufacturer | Kohler SV715 |
Fuel Type | Gasoline |
Configuration | 2-cylinder, air-cooled vertical-shaft V-Twin |
Displacement | 725 cc
44.24 ci |
Bore/Stroke | 3.27x2.64 inches
83 x 67 mm |
Power (gross) | 22 hp
16.4 kW |
Starter | electric |
Starter volts | 12 |
Transmission
| 2013 - 2024
Model year 2013-20142014-2024
RZT L SeriesZero-turn mower |
|---|---|
2013 - 2024 | |
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower | |
2013 - 2024 | |
|---|---|
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower |
Transmission — Hydro-Gear EZT-2200
Transmission | Hydro-Gear EZT-2200 |
Type | hydrostatic |
Gears | infinite forward and reverse |
Dimensions
| 2013 - 2024
Model year 2013-20142014-2024
RZT L SeriesZero-turn mower |
|---|---|
2013 - 2024 | |
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower | |
2013 - 2024 | |
|---|---|
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower |
Cub Cadet RZT L42 Tires | |
|---|---|
Lawn/turf front | 11x4-5 |
Lawn/turf rear | 18x8.5-8 |
Dimensions | |
|---|---|
Wheelbase | 43.5 inches
110 cm |
Length | 80 inches
203 cm |
Height | 36 inches
91 cm |
Weight | 480 lbs
217 kg |
Attachments
| 2013 - 2024
Model year 2013-20142014-2024
RZT L SeriesZero-turn mower |
|---|---|
2013 - 2024 | |
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower | |
2013 - 2024 | |
|---|---|
Model year 2013-20142014-2024 | |
RZT L Series | |
Zero-turn mower |
42" Mower deck | |
|---|---|
Type | mid-mount Cub Cadet |
2-blade | |
Cutting width | 42 inches
106 cm |
Overall width | 50 inches
127 cm |
Cut height | 1.5 to 4 inch
3 to 10 cm |
Photos
Cub Cadet RZT L42 tractor photo
