Deutz-Fahr 5115

The Deutz-Fahr 5115 is a tractor produced by Deutz Fahr. It is equipped with a 220.9 ci 3.6 L engine. The rated power output is 111.3 hp 83.0 kW. Transmission: SDF. Operating weight: 9921 lbs 4500 kg.

Overview

	2017 - 5 SeriesUtility tractor
2017 -
5 Series
Utility tractor

Production
Manufacturer	Deutz-Fahr
Utility tractor

Deutz-Fahr 5115 Engine
Deutz 3.6L 4-cyl diesel
Fuel tank	35.7 gal 135.1 L
Exhaust fluid (DEF)	2.1 gal 7.9 L
Engine details ...

Deutz-Fahr 5115 Power
Engine (gross)	111.3 hp 83.0 kW
Engine (max)	117.3 hp 87.5 kW

Mechanical
Four-wheel drive
Differential lock	electro-hydraulic front and rear
Power steering
Wet disc brakes
Trailer brakes	hydraulic OptOptional
	pneumatic OptOptional
Cab standard with available air-conditioning.

Hydraulics
Type	open center
Pump flow	14.5 gpm 54.9 lpm
	15.85 gpmOptOptional 60.0 lpm
	23.8 gpmOptOptional 90.1 lpm

Tractor hitch
Rear Type	II
Rear lift	7540 lbs 3420 kg
	10395 lbsOptOptional 4715 kg
	11596 lbsOptOptional 5259 kg
Front lift	4630 lbs 2100 kg

Power Take-off (PTO)
Rear PTO	independent
Clutch	electro-hydraulic
Rear PTO Type	540/540E
	1000/1000E OptOptional
Front PTO	independent OptOptional
Front PTO Type	1000

Dimensions & Tires
Wheelbase	93.3 inches 236 cm
Weight	9921 lbs 4500 kg
Front tire	420/85R24
Rear tire	460/85R34
Full dimensions and tires ...

Electrical
Ground	negative
Charging system	alternator
Charging amps	150
Charging volts	12
Battery CCA	650
Battery volts	12
Battery AH	100

References
5 Series published in 2016, by Deutz-Fahr

Engine

Engine Detail — 220.9 ci / 3.6 L Diesel

Manufacturer	Deutz TCD 3.6 L04
Configuration	turbocharged intercooled diesel, 4-cylinder, liquid-cooled
Displacement	220.9 ci 3.6 L
Bore/Stroke	3.86x4.72 inches 98 x 120 mm
Rated Power (gross)	111.3 hp 83.0 kW
Maximum Power (gross)	117.3 hp 87.5 kW
Rated RPM	2000
Torque	351.1 lb-ft 476.1 Nm
Torque RPM	1600
Starter	electric
Starter volts	12

Transmission

Transmission options
20-speed partial power shift
30-speed partial power shift

Transmission — SDF

Transmission	SDF
Type	partial power shift
Gears	20 forward and reverse
Five gears in two ranges with two-speed power shift and power shuttle. Also available with additional under-drive and super-creeper ranges, providing 40 total speeds in each direction.

Transmission — SDF

Transmission	SDF
Type	partial power shift
Gears	30 forward and reverse
Five gears in two ranges with three-speed power shift and power shuttle. Also available with additional under-drive and super-creeper ranges, providing 60 total speeds in each direction.

Dimensions

Deutz-Fahr 5115 Tires
Standard tires (ag)	Front: 420/85R24. Rear: 460/85R34
Optional tires (ag)	Front: 440/65R28. Rear: 540/65R38

Dimensions
Wheelbase	93.3 inches 236 cm
Length	163.2 inches 414 cm
Width	85.4 inches*Minimum width. 216 cm
Height	108.7 inches 276 cm
Shipping weight	9921 lbs 4500 kg
Max weight	16535 lbs 7500 kg
