Fendt F380GT
The Fendt F380GT is a tractor produced by Fendt. It is equipped with a 249.3 ci 4.1 L engine. The listed engine power is Diesel (listed): 80 hp / 59.7 kW. Transmission: 21 forward and 6 reverse. Drive type: 4x2 2WD. Operating weight: 8136 lbs (8775 MFWD) 3690 kg.
Engine Power
Diesel (listed): 80 hp / 59.7 kW
Drive & Traction
4x2 2WD
Fuel & Capacities
21.1 gal
79.9 L
Transmission
21 forward and 6 reverse
Operating Weight
8136 lbs (8775 MFWD)
3690 kg
Overview
 | 1984 - 1998 |
|---|
Production | |
|---|---|
Manufacturer | Fendt |
Fendt F380GT Engine | |
|---|---|
KHD 4.1L 4-cyl diesel | |
Fuel tank | 21.1 gal
79.9 L |
Engine details ...  | |
Fendt F380GT Transmission | |
|---|---|
21-speed | |
Transmission details ...  |
Fendt F380GT Power | |
|---|---|
Engine | 80 hp
59.7 kW |
Mechanical | |
|---|---|
Drive | 4x2 2WD |
4x4 MFWD 4WD optional | |
Hydraulics | |
|---|---|
Pump flow | 18.0 gpm
68.1 lpm |
Tractor hitch | |
|---|---|
Rear lift | 9657 lbs
4380 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540, 750 |
Dimensions & Tires | |
|---|---|
Wheelbase | 124.02 inches
315 cm |
Weight | 8136 lbs
3690 kg |
Front tire | 7.50-20 |
Rear tire | 16.9R34 |
Full dimensions and tires ...  | |
References | |
|---|---|
 | |
Allrad GT published in 1986, by Fendt | |
Innovations for 1988 published by Fendt |
Engine
Engine Detail — 249.3 ci / 4.1 L Diesel
Manufacturer | KHD |
Fuel Type | Diesel |
Configuration | 4-cylinder |
Displacement | 249.3 ci
4.1 L |
Bore/Stroke | 4.0157x4.92 inches
102 x 125 mm |
Power | 80 hp
59.7 kW |
Rated RPM | 2400 |
Torque | 191.8 lb-ft
260.1 Nm |
Torque RPM | 1550 |
Transmission
Transmission — 21 forward and 6 reverse
Gears | 21 forward and 6 reverse |
Dimensions
Fendt F380GT Tires | |
|---|---|
Ag front | 7.50-20 |
13.6R24 (4WD) | |
Ag rear | 16.9R34 |
Dimensions | |
|---|---|
Wheelbase | 124.02 inches
315 cm |
Length | 185.43 inches
470 cm |
Height | 103.54 inches
262 cm |
Weight | 8136 lbs (8775 MFWD)
3690 kg |
Photos
Fendt F380GT tractor photo
Recommended Implements & Sizing Guide
Engineering recommendations for Fendt F380GT based on its 80 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 7 to 8 ft (84-96 in)2.1 - 2.4 m | Heavy Duty | Heavy-duty twin spindle cutter for overgrown acreage. |
Rotary TillerSeedbed Prep | 78 to 84 in200 - 215 cm | Heavy Duty | Heavy commercial tiller with multi-speed gearbox. |
Disc HarrowSecondary Tillage | 10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙 | Heavy Duty | Aggressive residue cutting in corn/cotton stubble. |
Hay BalerHay & Forage | 4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机 | Heavy Duty | Silage and dry hay; 540 RPM PTO with slip-clutch. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Fendt F380GT.
Estimated Continuous Field Runtime: 5.1 hrs
Approximately 5.1 hours of continuous field operation at ~75% rated power on a full tank (21.1 gal / 79.9 L).
Estimated 75% Load Fuel Burn~4.2 gal/hr (15.7 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Fendt F380GT Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Fendt F380GT.
Converted Equivalents:
Horsepower (HP)80 hp
Kilowatts (kW)59.7 kW
Metric Horsepower (PS / CV)81.1 PS
Direct Competitor Comparison
Compare Fendt F380GT against same-era industry alternatives in the same horsepower class.
Current Model
Fendt
Fendt F380GT
Engine Power:Diesel (listed): 80 hp / 59.7 kW
★ Baseline Reference
