Fendt Favorit 10S

The Fendt Favorit 10S is a tractor produced by Fendt. It is equipped with a 311.2 ci 5.1 L engine. The listed engine power is Diesel (net): 80 hp / 59.7 kW; Diesel (gross): 90 hp / 67.1 kW. Transmission: 20 forward and 10 reverse. Operating weight: 8587 to 8940 pounds.

Overview

	1970 - 1972

Production
Manufacturer	Fendt
Built in Marktoberdorf, Germany

Fendt Favorit 10S Engine
MWM 5.1L 6-cyl diesel
Fuel tank	34.3 gal 129.8 L
Engine details ...

Fendt Favorit 10S Power
Engine (gross)	90 hp 67.1 kW
Engine (net)	80 hp 59.7 kW

Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Open operator station.

Tractor hitch
Rear lift	6615 lbs 3000 kg

Power Take-off (PTO)
Rear PTO Type	540/1000

Dimensions & Tires
Wheelbase	102.8 inches 261 cm
Weight	8587 to 8940 pounds
Front tire	7.50-20
2WD Rear tire	14-34
Full dimensions and tires ...

References
Favorit 10S published in 1970, by Fendt

Engine

Engine Detail — 311.2 ci / 5.1 L Diesel

Manufacturer	MWM D225
Fuel Type	Diesel
Configuration	6-cylinder, liquid-cooled
Displacement	311.2 ci 5.1 L
Bore/Stroke	3.74x4.72 inches 95 x 120 mm
Power (net)	80 hp 59.7 kW
Power (gross)	90 hp 67.1 kW
Rated RPM	2200
Starter volts	12

Transmission

Transmission options
16-speed
20-speed creeper

Transmission — 16 forward and 8 reverse

Gears	16 forward and 8 reverse
Transmission
Type	creeper
Gears	20 forward and 10 reverse

Dimensions

Fendt Favorit 10S Tires
2WD Standard tires (ag)	Front: 7.50-20. Rear: 14-34
4WD Standard tires (ag)	Front: 9-24. Rear: 14-34

Dimensions
Wheelbase	102.8 inches 261 cm
Length	173.2 inches 439 cm
Width	82.7 inches 210 cm
Height (steering wheel)	76.2 inches 193 cm
Height (ROPS)	100 inches 254 cm
2WD Weight	8587 lbs 3895 kg
4WD Weight	8940 lbs 4055 kg
Ground clearance	15.8 inches 40 cm

Photos

Fendt Favorit 10S
