Ford 5600
The Ford 5600 is a tractor produced by Ford. It is equipped with a 256 ci 4.2 L engine. The listed engine power is Diesel (listed): 75 hp / 55.9 kW. Transmission: 8 forward and 2 reverse. Operating weight: 5710 lbs 2590 kg.
Engine Power
Diesel (listed): 75 hp / 55.9 kW
Fuel & Capacities
21.5 gal
81.4 L
Transmission
8 forward and 2 reverse
Operating Weight
5710 lbs
2590 kg
Overview
 | 1982 - 1984 |
|---|
Production | |
|---|---|
Manufacturer | Ford |
Built in São Bernardo do Campo, Brazil | |
Ford 5600 Engine | |
|---|---|
Ford 4.2L 4-cyl diesel | |
Engine details ...  |
Ford 5600 Transmission | |
|---|---|
8-speed | |
Transmission details ...  |
Ford 5600 Power | |
|---|---|
Engine | 75 hp
55.9 kW |
PTO (claimed) | 65 hp
48.5 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Differential lock | mechanical rear |
Steering | mechanical |
hydrostatic power OptOptional | |
Wet disc brakes | |
Open operator station. | |
Capacity | |
|---|---|
Fuel | 21.5 gal
81.4 L |
Hydraulic system | 14 gal
53.0 L |
Hydraulics | |
|---|---|
Type | open center |
Capacity | 14 gal
53.0 L |
Pressure | 2646 psi
182.4 bar |
Pump flow | 9.7 gpm
36.7 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift (at 24"/610mm) | 4138 lbs
1876 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@1900 |
Dimensions & Tires | |
|---|---|
Wheelbase | 87.4 inches
221 cm |
Weight | 5710 lbs
2590 kg |
Front tire | 7.50x16 |
Rear tire | 13.6/12x38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Charging system | alternator |
Charging amps | 30 |
Battery volts | 12 |
Battery AH | 80 |
References | |
|---|---|
 | |
Ford 5600 |
Engine
Engine Detail — 256 ci / 4.2 L Diesel
Manufacturer | Ford OHV 4256 |
Fuel Type | Diesel |
Configuration | 4-cylinder, liquid-cooled |
Displacement | 256 ci
4.2 L |
Bore/Stroke | 4.4x4.2 inches
112 x 107 mm |
Power | 75 hp
55.9 kW |
Compression | 16.3:1 |
Rated RPM | 2100 |
Torque | 194.7 lb-ft
264.0 Nm |
Torque RPM | 1400 |
Starter | electric |
Starter volts | 12 |
Oil capacity | 9 qts
8.5 L |
Coolant capacity | 13 qts
12.3 L |
Transmission
Transmission — 8 forward and 2 reverse
Gears | 8 forward and 2 reverse |
Clutch | 330mm dry disc |
 | |
Dimensions
Ford 5600 Tires | |
|---|---|
Ag front | 7.50x16 |
Ag rear | 13.6/12x38 |
18.4/15x30 | |
16.9/14x30 | |
Dimensions | |
|---|---|
Wheelbase | 87.4 inches
221 cm |
Length | 141.7 inches
359 cm |
Width | 70.9 inches
180 cm |
Height (steering wheel) | 64.6 inches
164 cm |
Shipping weight | 5710 lbs
2590 kg |
Clearance (front axle) | 18 inches
45 cm |
22.1 inchesOptOptional
56 cm | |
Clearance (rear axle) | 16.5 inches
41 cm |
Front tread | 52 to 80 inches
132 to 203 cm |
Rear tread | 56 to 80 inches
142 to 203 cm |
Recommended Implements & Sizing Guide
Engineering recommendations for Ford 5600 based on its 75 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 3 to 4 Bottom (16")3 - 4 铧 (40 cm) | Heavy Duty | Suitable for medium loam and stubble turnover. |
Rotary Cutter / MowerMowing & Clearing | 7 to 8 ft (84-96 in)2.1 - 2.4 m | Heavy Duty | Heavy-duty twin spindle cutter for overgrown acreage. |
Rotary TillerSeedbed Prep | 78 to 84 in200 - 215 cm | Heavy Duty | Heavy commercial tiller with multi-speed gearbox. |
Disc HarrowSecondary Tillage | 10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙 | Heavy Duty | Aggressive residue cutting in corn/cotton stubble. |
Hay BalerHay & Forage | 4x4 to 4x5 Round Baler1.2x1.5 m 紧凑圆捆机 | Heavy Duty | Silage and dry hay; 540 RPM PTO with slip-clutch. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Ford 5600.
Estimated Continuous Field Runtime: 5.5 hrs
Approximately 5.5 hours of continuous field operation at ~75% rated power on a full tank (21.5 gal / 81.4 L).
Estimated 75% Load Fuel Burn~3.9 gal/hr (14.8 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Ford 5600 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Ford 5600.
Converted Equivalents:
Horsepower (HP)75 hp
Kilowatts (kW)55.9 kW
Metric Horsepower (PS / CV)76 PS
Direct Competitor Comparison
Compare Ford 5600 against same-era industry alternatives in the same horsepower class.
Current Model
Ford
Ford 5600
Engine Power:Diesel (listed): 75 hp / 55.9 kW
★ Baseline Reference
