Ford 7810
The Ford 7810 is a tractor produced by Ford. It is equipped with a 401 ci 6.6 L engine. The rated power output is 100 hp 74.6 kW. Transmission: Dual Power. Operating weight: 8228 to 9460 pounds.
Engine Power
100 hp
74.6 kW
Fuel & Capacities
35 gal
132.5 L
Transmission
Dual Power
Operating Weight
8228 to 9460 pounds
Ford 7810 Serial Number & Year Decoder
Find the exact manufacture year of your tractor by checking your chassis serial number below.
Where to Find the Serial NumberThe serial number plate is commonly located on the front frame, tractor transmission housing (right side), or instrument panel badge.
Overview
 | 1988 - 1991
Row-Crop tractor |
|---|---|
1988 - 1991 | |
Row-Crop tractor | |
Production | |
|---|---|
Manufacturer | Ford |
Row-Crop tractor | |
Original price was $32,000 in 1990 | |
Ford 7810 Engine | |
|---|---|
Ford 6.6L 6-cyl diesel | |
Fuel tank | 35 gal
132.5 L |
Engine details ...  | |
Ford 7810 Power | |
|---|---|
Engine (gross) | 105 hp
78.3 kW |
Engine (net) | 100 hp
74.6 kW |
PTO (claimed) | 86 hp
64.1 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Final drives | inboard planetary |
Differential lock | mechanical rear |
Cab optional. | |
Hydraulics | |
|---|---|
Type | open center |
Valves | 2 to 4 |
Pump flow | 18.2 gpm
68.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Rear lift | 4020 lbs
1823 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@1900 |
1000@2060 | |
Dimensions & Tires | |
|---|---|
2WD Wheelbase | 99.1 inches
251 cm |
4WD Wheelbase | 99.2 inches
251 cm |
Weight | 8228 to 9460 pounds |
Front tire | 10.00-16 |
2WD Rear tire | 16.9-38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
ROPS Charging amps | 51 |
Cab Charging amps | 75 |
Battery CCA | 750 |
Battery volts | 12 |
References | |
|---|---|
 | |
Generation III Tractors - Models 7810 and 8210 published in 1991, by Ford | |
7810 published in 1990, by Ford | |
7810 Low-Profile Tractor published in 1991, by Ford |
Engine
Engine Detail — 401 ci / 6.6 L Diesel
Manufacturer | Ford |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 401 ci
6.6 L |
Bore/Stroke | 4.4x4.4 inches
112 x 112 mm |
Power (net) | 100 hp
74.6 kW |
Power (gross) | 105 hp
78.3 kW |
Pre-heating | thermostart |
Rated RPM | 2100 |
Starter | electric |
Starter volts | 12 |
Coolant capacity | 16 qts
15.1 L |
Transmission
Transmission options | |
|---|---|
8-speed gear | |
16-speed |
Transmission — 8 forward and 2 reverse gear
Type | gear |
Gears | 8 forward and 2 reverse |
Transmission — Dual Power
Transmission | Dual Power |
Gears | 16 forward and 4 reverse |
Dimensions
Ford 7810 Tires | |
|---|---|
2WD Standard tires (ag) | Front: 10.00-16. Rear: 16.9-38 |
4WD Standard tires (ag) | Front: 14.9-24. Rear: 16.9-38 |
Dimensions | |
|---|---|
2WD Wheelbase | 99.1 inches
251 cm |
4WD Wheelbase | 99.2 inches
251 cm |
2WD Length | 157.6 inches
400 cm |
4WD Length | 165.7 inches
420 cm |
Width | 72.9 inches
185 cm |
2WD Weight | 8228 lbs
3732 kg |
4WD Weight | 9460 lbs
4291 kg |
Front tread | 52 to 80 inches
132 to 203 cm |
Rear tread | 56 to 90 inches
142 to 228 cm |
Ford 7810 Height | |
|---|---|
ROPS | 95.9 inches
243 cm |
97 inches (Low-Profile)
246 cm | |
Cab | 106.6 inches
270 cm |
Photos
European Ford 7810 Series II
Silver Ford 7810 Series III, right side.
Blue Ford 7810 Series III, left side.
