Ford 7910
The Ford 7910 is a tractor produced by Ford. It is equipped with a 401 ci 6.6 L engine. The listed engine power is Diesel (listed): 98 hp / 73.1 kW. Transmission: 16 forward and 8 reverse. Operating weight: 11,520 lbs (4WD) 5225 kg.
Engine Power
Diesel (listed): 98 hp / 73.1 kW
Fuel & Capacities
47 gal
177.9 L
Transmission
16 forward and 8 reverse
Operating Weight
11,520 lbs (4WD)
5225 kg
Overview
 | 1985 - 1987
Row-Crop tractor |
|---|
Production | |
|---|---|
Manufacturer | Ford |
Row-Crop tractor | |
Ford 7910 Engine | |
|---|---|
Ford 6.6L 6-cyl diesel | |
Fuel tank | 47 gal
177.9 L |
Engine details ...  | |
Ford 7910 Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
Ford 7910 Power | |
|---|---|
Engine | 98 hp
73.1 kW |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes |
Hydraulics | |
|---|---|
Pump flow | 18.2 gpm
68.9 lpm |
Tractor hitch | |
|---|---|
Rear lift | 9039 lbs
4100 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 113.8 inches
289 cm |
Weight | 11,520 lbs
5225 kg |
Front tire | 11.00-16 |
Rear tire | 16.9-38 |
Full dimensions and tires ...  | |
Engine
Engine Detail — 401 ci / 6.6 L Diesel
Manufacturer | Ford |
Fuel Type | Diesel |
Configuration | 6-cylinder, liquid-cooled |
Displacement | 401 ci
6.6 L |
Bore/Stroke | 4.40x4.40 inches
112 x 112 mm |
Power | 98 hp
73.1 kW |
Rated RPM | 2100 |
Torque | 287.6 lb-ft
390.0 Nm |
Torque RPM | 1000 |
Transmission
Transmission — 16 forward and 8 reverse
Gears | 16 forward and 8 reverse |
Dimensions
Ford 7910 Tires | |
|---|---|
Ag front | 11.00-16 (2WD) |
13.6-28 (4WD) | |
Ag rear | 16.9-38 |
Dimensions | |
|---|---|
Wheelbase | 113.8 inches
289 cm |
Length | 172 inches
436 cm |
Height | 110.2 inches
279 cm |
Weight | 11,520 lbs (4WD)
5225 kg |
Photos
Ford 7910
Recommended Implements & Sizing Guide
Engineering recommendations for Ford 7910 based on its 98 HP power envelope and ASAE agricultural standards.
| Implement & Operation | Recommended Size | Workload Rating | Engineering Notes |
|---|---|---|---|
Moldboard PlowPrimary Tillage | 4 to 5 Bottom (16-18")4 - 5 铧 (40-45 cm) | Heavy Duty | Heavy primary tillage; semi-mounted hitch recommended. |
Rotary Cutter / MowerMowing & Clearing | 10 to 12 ft Flex-Wing3.0 - 3.6 m 折叠双翼 | Heavy Duty | Wide swath pasture and crop residue shredding. |
Rotary TillerSeedbed Prep | 78 to 84 in200 - 215 cm | Heavy Duty | Heavy commercial tiller with multi-speed gearbox. |
Disc HarrowSecondary Tillage | 10 to 14 ft Tandem / Offset3.0 - 4.2 m 重型交错耙 | Heavy Duty | Aggressive residue cutting in corn/cotton stubble. |
Hay BalerHay & Forage | 5x6 Round Baler or 3x3 Mid Square1.5x1.8 m 大圆捆或中型方捆机 | Heavy Duty | High density baling; requires minimum 85 PTO HP. |
Sizing & Soil Condition NoteActual implement sizing varies depending on local soil conditions (heavy clay vs sandy loam), field slope, and operating speed. Heavy tillage implements may require front ballast weights and wheel weights.
Fluids, Capacities & Working Autonomy
Standard fluid requirements, service intervals, and continuous runtime estimates for Ford 7910.
Estimated Continuous Field Runtime: 9.2 hrs
Approximately 9.2 hours of continuous field operation at ~75% rated power on a full tank (47 gal / 177.9 L).
Estimated 75% Load Fuel Burn~5.1 gal/hr (19.3 L/hr)
Engine Crankcase Oil
SAE 15W-40 (Heavy Duty Diesel)
Standard Spec: API CK-4 / CJ-4 Heavy Duty
Service Interval: 150 – 250 Hours
Transmission & Hydraulic System
UTTO (Universal Tractor Transmission Oil)
Standard Spec: ISO VG 46 / 68 (Wet Brake & Trans Compatible)
Service Interval: 600 – 1000 Hours
Engine Cooling System
50/50 Ethylene Glycol Pre-mix
Standard Spec: ASTM D6210 / Heavy-Duty OAT Antifreeze
Service Interval: 2 Years / 1500 Hours
Ford 7910 Specification Unit Converter
Convert power, fluid capacities, and operating weights between metric and imperial standards for Ford 7910.
Converted Equivalents:
Horsepower (HP)98 hp
Kilowatts (kW)73.1 kW
Metric Horsepower (PS / CV)99.4 PS
Direct Competitor Comparison
Compare Ford 7910 against same-era industry alternatives in the same horsepower class.
Current Model
Ford
Ford 7910
Engine Power:Diesel (listed): 98 hp / 73.1 kW
★ Baseline Reference
International HarvesterMarket Competitor
International Harvester 766
Engine Power:88.6
Production Years:1971 - 1976
